Smoking and Waiting Shelters
Description

Functional and robust in their design, the AUTOPA open spaces Smoking and Waiting Shelters provide protection from the elements. The frame is manufactured from high quality aluminium and the side and roof panels are manufactured from UV stable PETG sheet. Smoking shelters are 50% enclosed, making them compliant with UK and Irish legislation. Waiting shelters are fully enclosed shelters suitable for a variety of applications. Location of smoking shelters in relation to other structures can affect their compliance.

Features:

  • Offer wind and rain protection.
  • Smoking shelters help to promote a smoke free workplace.
  • Made from a strong aluminium frame.
  • Powder coated finish, grey as standard. Other colours available on request.
  • Side panels made of 5 mm vandal resistant, self-extinguishing clear UV stable PETG glazing.
  • For bolting down only.
  • Adjustable foot fixing for uneven surfaces (adjustable by 70 mm).
  • Perch bench option available extra.

General information

Size

2 x 1 m Smoking Shelter: 138000215

2 x 2 m Smoking Shelter: 138000225

2 x 3 m Smoking Shelter: 138000235

2 x 4 m Smoking Shelter: 138000245

2 x 5 m Smoking Shelter: 138000255

Show more

Features

Offer wind and rain protection

Smoking shelters help to promote a smoke free workplace

Made from a strong aluminium frame

Powder coated finish, grey as standard. Other colours available on request

Side panels made of 5 mm vandal resistant, self-extinguishing clear UV stable PETG glazing

Show more

Uniclass 2015

Pr_20_65_78_77 Semi-closed sheltersPrimary

CAWS

B91/390 Smoking shelter

B91/420 Waiting shelter

Specification data - Semi-closed shelters

Product Reference

Smoking and Waiting Shelters

Size

2 x 1 m Smoking Shelter: 138000215

2 x 2 m Smoking Shelter: 138000225

2 x 3 m Smoking Shelter: 138000235

2 x 4 m Smoking Shelter: 138000245

2 x 5 m Smoking Shelter: 138000255

2 x 6 m Smoking Shelter: 138000265

2 x 1 m Waiting Shelter: 138000100

2 x 2 m Waiting Shelter: 138000200

2 x 3 m Waiting Shelter: 138000230

2 x 4 m Waiting Shelter: 138000240

2 x 5 m Waiting Shelter: 138000250

2 x 6 m Waiting Shelter: 138000260

Colour/ Finish

Colour coated

Insert colour requirements.

Accessories

None

Ashtray, 138174142

Large fixed wall ashtray.

Perch bench,138000050

Standard product features

Size:

  • Height: 2330 mm.
  • Width: 2050 mm.

Product Options

Colour/ Finish:

Most RAL and BS colours are available as painted finishes – contact manufacturer for further details. Polyester coloured coatings are available by special order.

Accessories:

- Ashtray:

External wall cigarette disposal bin with a new improved design for easier use. Powder coated ‘Zintec’ steel body with textured finish, the ashtray features stubbing area, rain hood and integral ash collection box. The door is lockable with universal key. Comes supplied with fixing kit.

  • Height: 390 mm.
  • Width: 280 mm.
  • Depth: 140 mm.
