SLA3 Fastener - ACM Panel Fastener

Application

This fastener fixes aluminium composite panels, capable of being used for both fixed point and flexible point applications.

Description

A2 (1.4301 [304] grade) austenitic stainless steel self drilling fastener for aluminium composite panels (ACM) to aluminium support systems. The head form comes available in low profile 12 mm diameter with a torx20 drive (fiction fit drive).

This fastener fixes aluminium composite panels, capable of being used for both fixed point and flexible point applications.


Features and benefits:

Under the head is a free spin zone, which enables the components to be clamped tightly together and prevents over torqueing on fixed point applications and also to allow movement on flexible point applications.

This feature also enables the installer to not have to pre-drill aluminium framework, significantly improving installation speed compared to a rivet solution.


Drill capacity:

Can drill 4 mm ACM panel up to 2.5 mm aluminium.


Clamping range:

The unique free spin zone also allows for a clamping range of 3–6.3 mm.


General information

Color

Other

Powder coated to suit project.

Silver

Finish

Powder coated

Mill

Material

Stainless steel

Size

4.8 mm

WarrantyDescription

25 year

Up to 25 years - consult manufacturer.

Uniclass 2015

Pr_20_29_76_76 Self-drilling screwsPrimary

CAWS

H20/10 Sheet cladding

H20/150 Sheet cladding

H92/120 Rainscreen cladding

Specification data - Self-drilling screws Enhanced data

Material

Stainless steel A4.

Finish

Powder coated.

Mill.

Head type

12 mm dome head

Size

-

Diameter

4.8 mm.

Length

19 mm.

Washers

None.

Product Reference

SLA3 Fastener- ACM Panel Fastener
