Silentwall® Acoustic Panelling
Description

Versatile, noise reducing, high pressure laminate bonded wall panelling. Silentwall® is a noise-reducing development of the modular Parqwall® system. It is designed to absorb noises from highly frequented rooms and with a high level of background disturbance. They can be used for both aesthetic and acoustic installations and is suitable for cladding walls of any type and any condition, offering a fast and effective refurbishment solution. Depending on the backing system used, Parqwall allows space behind the panels to run essential services and can also be used to level uneven walls. It can be installed on vertical or horizontal wood spacers or on a galvanized steel frame.

Panels are produced from the section of a compound material consisting of an HDF wooden fibre core with an external Print® HPL laminate surface on each side. Noise reduction is obtained by milling parallel to the short side on the back of the panel and parallel to the long side on the décor, creating a 20% surface perforation. The panels are also milled along the sides creating a groove suitable for the insertion of the aluminium profiles making up the panel support structure to the wall. The profiles are of silver anodized aluminium and enable the installation of the panels both horizontally and vertically.

It is available with both visible anodized aluminium joints and fold-away joints, which allow the cladding material to display a completely unbroken surface. Special joints are also available which allow both horizontal and vertical fixing of racks. Although hard and durable, the material recreates the warmth typical of wood and other natural materials. Best sound absorption properties are achieved with the insertion of an insulation sheet between the panel and the wall and it is ideal for absorbing medium to high frequencies in applications such as offices, conference rooms and theatres.

Features:

  • Anti-stain.
  • Anti-vandalism properties.
  • Good resistance to dampness.
  • Sound proofing/ insulating.
  • Thermally insulating.

General information

Features

Anti-stain

Anti-vandalism properties

Good resistance to dampness

Sound proofing/ insulating

Thermally insulating

Uniclass 2015

Pr_25_71_97_22 Decorative laminated plastics sheet veneered panelsPrimary

CAWS

K13/140 Proprietary laminated plastics-veneered panel lining

K13/160 Proprietary

K13/170 Acoustic panel lining

K30/10 Relocatable partition system

K30/130 Relocatable partition system

Specification data - Decorative laminated plastics sheet veneered panels

Product Reference

Silentwall®

Type

Horizontal

Vertical

Width

400 mm

600 mm

Laminate

-

Type

Colours

Colours and Textures

Decori Minimi

Legni

Legni News

Milano

Colour

Insert requirement.

Finish

Insert requirement.

Profiles

Not required

Click aluminium corner joint with support

Double head or end profile

End profile for inside corners

Fold-away profiles

Fold-away two-way joint

Head or end profile

Horizontal joint allowing the fixing of shelves and accessories

Panelling end profile

Rack joint

Two-way joint

Standard product features

Thickness:

0.9 mm.

Length:

2400 or 3000 mm dependent on colour range; consult manufacturer's literature for more information.

Noise reduction coefficient:

  • Low frequency (100–315 Hz): 0.28.
  • Medium frequency (400–1250 Hz): 0.73.
  • High frequency (1600–5000 Hz): 0.41.

Fire rating:

Class B-s2,d0.

Product Options

Colour/ Finish:

Many colour options are available; consult manufacturer's literature for more information. Finish options are dependent on colour choice.
