Sheldon Standard Canopy

Verified by manufacturer 3 months ago

Tall Freestanding Monopitch - SCP307

Langley Design Variant:
Third party certifications:
  • CHAS

    CHAS

    Certificate type

  • Constructionline Gold

    Constructionline Gold

    Certificate type

  • ISO 45001 Health and Safety Management

    Certificate type

  • ISO 9001 Quality Management

    Certificate type

  • Alcumus SafeContractor

    Alcumus SafeContractor

    Certificate type

Freestanding timber monopitch canopy.

Jump to:
+44 (0)1793 759461 Website

Application

Suitable for external, commercial applications.

Description

The Sheldon Standard Canopy is Langley's standard timber freestanding monopitch canopy with either a polycarbonate, R32 profiled metal or sedum roof protecting the interior from the elements. The canopy comes in two size variants with the tall achieving a wider span and taller overall height. The canopy design is modular meaning it can have a single bay and then add extension bays until the desired amount of bays is reached, however is customizable in length, width and available in a range of timber materials.


The Sheldon Standard Canopy can be fixed directly to a suitable finished surface or fixed down below finished ground level depending on site requirements. The canopy comes as standard with a galvanized finish which can be left in its natural finish or can be powder coated to any RAL colour to match the projects requirements.


Features and benefits:

  • Freestanding timber monopitch canopy.
  • Two size variants with the tall achieving a wider span and taller overall height.
  • Modular meaning with multiple extension bays as options.
  • Customizable in length and width.
  • Available in a range of timber materials.
  • The galvanized finish can be powder coated to any RAL colour.
  • Available with sedum roof if required


Click here to see more of our extensive Street Furniture product range

General information

Color

Beige

Black

Blue

Brown

Cream

Show more

Finish

Galvanized

Powder-coated

Material

Timber

Steel

Shape

Rectangle

Length

4630 mm

Bespoke

Width

2700 mm

3700 mm

Bespoke

Height

2600 mm

3320 mm

Bespoke

Warranty description

Three year

Uniclass

Pr_20_65_78_58 Open-sided sheltersPrimary

CAWS

B91/335 Covered walkway

B91/385 Shelter

B91/330 Canopy

Specification data - Open-sided shelters

Description

Tall freestanding canopy.

Manufacturer

Langley Design.

Shelter description

Rectangular, monopitch roof.

Dimensions

-

Plan size

4630 x 3700 mm.

Bespoke.

Guidance for specification option:

Consult manufacturer and insert requirements.

Height

3320 mm.

Bespoke.

Guidance for specification option:

Consult manufacturer and insert requirements.

Frame

-

Material

Treated class 3 Redwood (TRC3).

Treated class 4 Redwood (TRC4).

Treated class 3 Redwood - dark oak stain (TRC3-DO).

Treated class 4 Redwood - dark oak stain (TRC4-DO).

Hardwood Iroko (HI).

Finish

Galvanized (GL) steel.

Galvanized and powder-coated (GPC) steel.

Manufacturer guidance

Metal finish.

Colour

-

Manufacturer guidance

Insert requirements. Can be powder-coated to any RAL colour.

Roof covering

Polycarbonate.

R32 profiled metal.

Sedum.

Non-fragile polycarbonate.

Base

Below ground base fix.

Surface mount.

Sustainability data

Contains Red List materials

No

Country of product manufacture

United Kingdom

Material

Timber

Steel

Manufacturing plant location

Third party certifications

CHAS

CHAS

CHAS

Constructionline Gold

Constructionline Gold

Constructionline Gold

ISO 45001 Health and Safety Management

ISO 45001 Health and Safety Management

ISO45001:2018 Occupational Health & Safety Management System

ISO 9001 Quality Management

ISO 9001 Quality Management

ISO9001:2015 Quality Management System

Alcumus SafeContractor

Alcumus SafeContractor

SafeContractor
