Application

Can provide:

  • 110 cups of boiling water per hour.
  • Unlimited ambient water.

Description

Instant filtered drinking water system.

Features and benefits:

  • Provides both boiling and ambient water at the touch of a lever.
  • Uses high performance Eco-Intelligence technology and insulation materials to improve efficiency; the self-learning timer monitors daily usage patterns and recognises evening and weekend changes in routine to minimize energy consumption and only operate when required.
  • Includes a standby mode, which will ensure that after a set period of non-usage, the unit will power down to prevent excess energy consumption.
  • Space-saving.
  • Does not require the use of cupboard ventilation or a cooling fan.
  • SplashFree™ system electronically varies the boiling water flow, adjusting to eliminate splashing.
  • Includes a safety switch.
  • Boiling water is dispensed at 98.5°C as standard. The boiling water reserve ensures boiling water is always readily available.
  • The filtration system removes sediment, chemicals, heavy metals, chlorine and pesticides, allows the flow of minerals through and suppresses harmful bacteria in the water.
  • Supplied with a 0.9 m flex cord and plug.
  • 24-month warranty.

Applications:

Can provide:

  • 110 cups of boiling water per hour.
  • Unlimited ambient water.

Compliance:

  • WaterMark™ and WRAS approved.
  • Certified to AS3498 and AS/ NZS 4020.

General information
Color

Chrome

Features

Low energy consumption; eco-intelligence™ technology; small under-counter footprint; unlimited ambient; no cupboard ventilation required; safety first, boiling water, standby mode

Size

15

WarrantyDescription

24 month parts and labour warranty

Uniclass 2015 Instant boiling and cold water taps (Pr_40_70_23_42)
Specification data
Product Reference

Sahara 320 (943020)

Dispenser -
Type

XL Levered (L)

Standard.

XT Touch (T)

XR Remote (R)

Finish

Brushed Chrome (BR)

Available for XL Levered and XT Touch only.

Brushed Rose Gold

Available for XL Levered only.

Chrome (CH)

Standard. Available for all dispenser types.

Florentine Bronze

Available for XL Levered only.

Gloss Black

Available for XL Levered only.

Gun Metal Grey

Available for XL Levered only.

Matte Black (MB)

Available for XL Levered and XT Touch only.

Matte White (MW)

Available for XL Levered and XT Touch only.

Platinum

Available for XL Levered only.

Rose Gold (RG)

Available for XL Levered and XT Touch only.

Special Finish (SP)

Available for XL Levered only.

Urban Brass

Available for XL Levered only.

Accessories/ Other requirements -
Font with 120 mm riser

Required

Not required

120 mm riser

Required

Not required

Tubing extension kit (990720)

Required

Not required

Standard product features

Size (h x w x d):

340 x 180 x 460 mm.

Technical characteristics:

  • Power outlet: 13 A.
  • Water pressure: 2.5–10 bar.
  • Water supply: A single 15 mm (1/2") stop-tap with a male thread should be installed.
  • Drainage connection: 1 1/2" upstand or appliance spigot on sink waste.

Consult manufacturer for further details.

Product Options

Dispenser:

The standard dispenser and finish is XL Levered (L) in chrome (CH) - 943020LCHUK. Consult manufacturer for further details.

Accessories/ Other requirements:

Most accessories are available in Chrome (CH), Brushed Chrome (BR), Matte Black (MB), Matte White (MW), Rose Gold (RG) or Special Finish (SP). Consult manufacturer for further details.

Digital objects
PlatformCompatibleVersionCertified to
Revit
Revit 2017 2 2.1
IFC
- 2 2.1
