Description

A selection of clear safety/ security window films designed to create a potentially life-saving barrier by reducing the risk of breakage during impact and holding glass fragments in place if breakage occurs. Can protect personnel and property in the event of accidental or deliberate glass breakage including Bomb Blast Mitigation.

WFC-SSS100 and SSS200 combines solar control properties with high grade safety/ security and is extensively used for bomb blast protection. These two films reduce high levels of incoming solar energy/ glare and give an external mirrored look which can upgrade the appearance of a building.

Compatability:

Not all window films are suitable for all glass types – consult The Window Film Company® for details.

Installation:

This type of window film must be installed by The Window Film Company® to ensure that it complies with the highest possible installation standards to validate the warranty of the product.

Samples:

Contact manufacturer to obtain samples and additional product literature or visit www.windowfilm.co.uk.

Standards:

All films upgrade glass to meet the requirements of BS 6206 and BS EN 12600: see listings below for exact standards met by each film type.

The Window Film Company® can advise on which thickness of films should be applied to different size windows/ thickness of glass and locations within a building to comply with current Health and Safety standards.

Window film complies with BS 476-6 and -7, Class 0 – Surface Spread of Flame and Ignitability.

Warranty:

Ten year manufacturer’s warranty supplied when professionally installed internally. The external grade 100 Micron Clear has a four year warranty when applied onto vertical glazing by The Window Film Company®.

General information
Specification data - Plastics window films
Product Reference

Safety/ Security/ Bomb Blast Window Film

Type

WFC-CSS100

Clear, 100 µm.

WFC-CSS175

Clear, 175 µm.

WFC-SSS200

Clear, 200 µm.

WFC-CSS300

Clear, 300 µm.

WFC-SSS100

Silver, 100 µm.

WFC-SSS200

Clear, 200 µm.

Product Options

Type:

Clear window films:

- WFC-CSS100:

  • Film thickness: 100 µm.
  • Tensile strength at break: 28,500 psi.
  • Break strength: 112 lb/ inch.
  • Elongation at break: 125%.
  • Peel strength: 7 lb/ inch
  • Ply: 1.
  • Safety rating: EN12600 2B2.

- WFC-CSS175:

  • Film thickness: 175 µm.
  • Tensile strength at break: 26,000 psi.
  • Break strength: 180 lb/ inch.
  • Elongation at break: 140%.
  • Peel strength: 7 lb/ inch.
  • Ply: 1.
  • Safety rating: EN12600 1B1.

- WFC-CSS200:

  • Film thickness: 200 µm.
  • Tensile strength at break: 28,500 psi.
  • Break strength: 224 lb/ inch.
  • Elongation at break: 125%.
  • Peel strength: 7 lb/ inch.
  • Ply: 2.
  • Safety rating: EN12600 1B1.

- WFC-CSS300:

  • Film thickness: 300 µm.
  • Tensile strength at break: 28,500 psi.
  • Break strength: 336 lb/ inch.
  • Elongation at break: 125%.
  • Peel strength: 7 lb/ inch.
  • Ply: 3.
  • Safety rating: EN356 P2A.

Solar Window Films (combined with Safety/Security Window Film):

- WFC-SSS100:

  • Film thickness: 100 µm.
  • Tensile strength at break: 28,500 psi.
  • Break strength: 112 lb/ inch.
  • Elongation at break: 125%.
  • Peel strength: 7 lb/ inch.
  • Ply: 2.
  • Safety rating: EN12600 2B2.
  • Total solar energy rejected: 78.0%.
  • Glare reduction: 81.0%.
  • Visible light transmission: 17.0%.
  • Ultra violet light rejected: 99.0%.

- WFC-SSS200:

  • Film thickness: 100 µm.
  • Tensile strength at break: 28,500 psi.
  • Break strength: 224 lb/ inch.
  • Elongation at break: 125%.
  • Peel strength: 7 lb/ inch.
  • Ply: 2.
  • Safety rating: EN12600 1B1.
  • Total solar energy rejected: 80.0%.
  • Glare reduction: 85.0%.
  • Visible light transmission: 14.0%.
  • Ultra violet light rejected: 99.0%.
