Rockpanel Lines²

Rockpanel Lines²

Rockpanel Third party certifications:
  • QA Certificate

    QA Certificate

    Certificate type

Board material for exterior (facade) cladding with a tongue and groove edge.

Jump to:
+44 (0)1656 863210 www.rockpanel.co.uk

Application

Can be applied in a range of projects including residential and commercial. Typical areas include ventilated facade cladding; tongue and groove sidings; suitable for horizontal or vertical installation.

Description

Board material for exterior (facade) cladding with a tongue and groove edge.


Features and benefits:

  • Produced from compressed natural basalt, a sustainable and readily available volcanic rock and bonded with an organic binder.
  • As durable as stone: resistant to the elements.
  • As workable as wood: the product is lightweight and can be cut to size on site.
  • Quick and easy to install.
  • Can be installed horizontally or vertically, and widths can be combined.
  • Low maintenance: the building will retain its original looks for many years.

General information

Features

Durable as stone. Quick and easy to install as wood. Classic planks with tongue and groove profile

Finish

Manufacturer's standard

Material

Compressed rock fibre

Shape

Rectangular (plank)

Size

10 x 164 x 3050 mm

Dependent on variant specified.

10 x 295 x 3050 mm

WarrantyDescription

10 years

Ten-year project specific warranty on application

Uniclass 2015

Pr_25_71_14_20 Compressed rock fibre panelsPrimary

CAWS

H20/150 Sheet cladding

H20/155 Sheet cladding

H92/120 Rainscreen cladding

Specification data - Compressed rock fibre panels Enhanced data

Third-party product certification

ETA-13/0204

Panel size

-

Length

3050 mm

Width

164 mm

Dependent on variant specified.

295 mm

Dependent on variant specified.

Panel thickness

10 mm

Edge profile

Tongue and groove

Finish as delivered

Manufacturer's standard

Colour

RAL 1015

RAL 7004

RAL 7016

RAL 9001

RAL 9010

RAL, custom

Insert requirements.

Basic primer

Reaction to fire

-

Panel internal face

European fire class B-s2,d0

Panel external face

European fire class B-s2,d0

Product Reference

Rockpanel Lines² 10 S

Width: 164 mm (working width: 146 mm)

Rockpanel Lines² 10 XL

Width: 295 mm (working width: 277 mm).

Combustibility

European fire class B-s2,d0

Environmental information

Recyclability

Recyclable

Recycled content

50

Literature

Rockpanel External Cladding Product Range

Rockpanel External Cladding Product Range

ROCKPANEL Instruction Guide

ROCKPANEL Instruction Guide

Third party certifications

QA Certificate

QA Certificate

European Technical Assessment (ETA): ETA-13/0204
