Application

Suitable for:


  • External facades.
  • Roofline detailing.
  • Internal and external detailing.
  • Soffits and fascias.
  • Dormers.
  • Infills.
  • Suitable for buildings over 18 m.


Durable Fire rated to EN 13501-1 class B-s2,d0 FS-Xtra Fire rated to EN 13501-1 class A2-s1, d0 This range is suitable for buildings over 18m. A versatile plank board for traditional façade solutions.


Description

Rockpanel is a fire-rated, versatile plank board which has been manufactured using compressed natural basalt bonded with an organic binder.


Features and benefits:

  • Fire rated option of EN 13501-1 class A2-s1, d0.
  • Easy to install and low maintenance.
  • Almost 100% recyclable.
  • Lightweight and easy to install.
  • Exceptional weather resistance.
  • More than 200 colours, surface finishes and patterns.
  • Customised solutions.
  • Integrates with other RCM products.
  • The boards are finished with a 4 layer water-based coating to seal in the appearance and colour to provide a lasting finish.

General information

Color

Grey

White

Finish

Coated

Water-based coating.

Material

Steel

Timber

Concrete

Shape

Rectangle

Length

2500 mm

3050 mm

Width

1200 mm

Uniclass

Pr_25_71_14_20 Compressed rock fibre panelsPrimary

CAWS

H20/150 Sheet cladding

H20/155 Sheet cladding

H92/120 Rainscreen cladding

H20/10 Sheet cladding

Specification data - Compressed rock fibre panels

Panel size

-

Length

2500 mm.

3050 mm.

Width

1200 mm.

Panel thickness

6 mm.

8 mm.

9 mm.

Finish as delivered

Consult manufacturer and insert requirement.

Colour

Signal grey.

RAL 7004.

Anthracite grey.

RAL 7016.

Dusty grey.

RAL 7037.

Pure white.

RAL 9010.

Metallics aluminium white.

RAL 9006.

Special order.

Colour ranges available upon order. Consult manufacturer and insert requirement.

Frame options

Lightweight steel.

Timber.

Concrete.

Modular / Offsite.

Fixings

Adhesive fix.

Rivet fix.

Screw fix.

FireRating

Durable Fire rated to EN 13501-1 class B-s2,d0 FS-Xtra Fire rated to EN 13501-1 class A2-s1, d0 This range is suitable for buildings over 18m.


A2-s1,d0.

B-s2,d0.

Environmental information

Recyclability

100%

Literature

Rockpanel MPA_176222 Reaction to fire classification FS-Xtra

Rockpanel MPA_176222 Reaction to fire classification FS-Xtra

Rockpanel European Technical Assessment

Rockpanel European Technical Assessment

Rockpanel Environmental Product Declaration

Rockpanel Environmental Product Declaration

Rockpanel Brochure

Rockpanel Brochure

Declaration of Performance - Rockpanel 9mm

Declaration of Performance - Rockpanel 9mm

Declaration of Performance - Rockpanel 8mm

Declaration of Performance - Rockpanel 8mm

Declaration of Performance - Rockpanel 6mm

Declaration of Performance - Rockpanel 6mm
