REGUPOL® Walkway - Rubber Interlocking Tile
Verified by manufacturer 4 days ago
REGUPOL® Walkway Standard - 30 mm thickness
REGUPOL® Walkway Standard - 30 mm thickness
ISO 14025
Certificate type
Cradle to Cradle Certified
Certificate type
Roofing and pavement tiles.
Application
Key applications for the rubber interlocking tiles include:
- Flat roofs.
- Access paths.
- Terrace/ balconies.
- Adjacent to CAT ladders/ access.
- Route-ways for solar installations.
- Route-ways for M&E access.
Description
REGUPOL® Walkway elastic roof and paving tiles are used to mark maintenance paths on flat roofs, while simultaneously protecting the waterproofing system.
They are used on solar, RLT, lightning protection or any other technical installations that require regular maintenance. Thanks to a simple dowel plug-in system, the walkway tiles are easy to install and ready for use immediately.
REGUPOL® Walkway Standard is flame-retardant is resistant to flying sparks and radiant heat, in accordance with DIN CEN/TS 1187:2012-03. This visual contrast to the roof sealing means they can also mark the maintenance paths very clearly, even when visibility is poor. In wet conditions, the walkway standard tiles allows good drainage and is non-slip.
It is classified as a "hard roofing" in accordance with abP P-MPA-E-21-507.
Features and benefits:
- Integrated drainage channels.
- Doul interlocking system.
- Can be cut to suit.
- UV stable.
- Available in a variety of colours.
- Impact absorbing and porous.
- Provides fire and smoke resistance.
General information
Color | Red Brown Black Green |
Finish | Anti-skid |
Material | Polyurethane (PUR) Rubber Foil |
Shape | Rectangle |
Length | 1000 mm |
Width | 500 mm |
Height | 30 mm 43 mm |
Warranty description | Two year Guidance for specification option: REGUPOL Walkway Alu. Five year Guidance for specification option: REGUPOL Walkway Standard. |
Uniclass | |
CAWS | J42/485 Membrane walkway J42/10 Warm deck roof covering |
SKU Code | REGWALK |
Product range |
Specification data - Membrane walkways
Supplied by | Rubbertech Ltd. |
Product reference | REGUPOL® Walkway Standard - 30 mm thickness. |
Third-party certification | Cradle to Cradle Certified. |
Performance characteristics | Classified as a "hard roofing" in accordance with abP P-MPA-E-21-507. |
Environmental performance requirements | |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 95%. |
Material | |
UV stabilization | Required. Manufacturer guidanceUV Stable. |
Finish | Slip-resistant. |
Width (minimum) | 500 mm. |
Thickness (minimum) | 30 mm. |
Colour | Red. Black. Green. |
Material | Polyurethane (PUR) bonded rubber granules. |
Water permeability | To DIN 18035-6, 0.5 cm/sec. |
TensileStrength | To DIN EN ISO 1798, 0.6 N/mm². |
Elongation at break | To DIN EN ISO 1798, 50%. |
Fire resistance | To DIN EN 13501-5, Broof(t1). |
Weight | 25.76 kg/m². |
Sustainability data
Contains Red List materials | No |
Country of material origin | Germany |
Country of product manufacture | Germany |
Material | Polyurethane (PUR) Rubber Foil |
A1-A3 (production stage) | Embodied carbon as defined in BS EN 15804 |
Normalised unit | 1136.4 kg CO₂ eq/kg |
Declared unit | 1 kg CO₂ eq/m² Self-declared |
Recyclability | 99% Recyclable |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 95 % |
Expected Life | Ten year |
Product certifications
Product certifications
ISO 14025
Environmental product declaration
Cradle to Cradle Certified
REGUFOAM solutions for acoustical, vibration and noise abatement
Literature
Literature type
Regupol Walkway Standard 43 mm Data Sheet
NEW LIFE - Certificate Top Recycled Product
Regupol® Walkway - Installation Guidance
Regupol Walkway Standard 30 mm Data Sheet
