Certifire Certificate
Certificate type
QA Certificate
Certificate type
Fire-resistant laminated glass.
The Pyrobel range of fire resistant glasses are tested and approved according to BS 476-22:1987, on both integrity and insulation criteria. Pyrobel is a fully transparent, multi-laminated glass assembled in clear intumescent fire resistant interlayers, available in large sizes, which offers valuable sound reduction properties and complies with the safety requirements of BS 6202/EN 12600 . In the event of fire, these interlayers expand at around 120°C and transform into a rigid and opaque shield.
Advantages:
Applications:
Pyrobel Visionline:
Much larger expanses of clear glazing are possible with Visionline, without compromising the protection required by the Standards. The system uses multiple Pyrobel fire-rated glazing panels, separated by 4–5 mm of space, which is filled with fire resistant cure silicone caulking - providing clear, unobstructed views and the ultimate in fire protection. With the absence of intermediate framing, the Pyrobel Visionline transparent wall offers continuous views and uncompromising beauty.
Performance:
Consult manufacturer's literature for full performance details of all products and fire tested glazing systems.
Size | Larger expanses of glazing are possible with Pyrobel Visionline; consult manufacturer for all permissible sizes. |
Uniclass 2015 |
Product Reference | Pyrobelite 730 minutes integrity/ low radiation glass. Pyrobelite 1260 minutes integrity/ low radiation glass. Pyrobel 1630 minutes integrity/ 30 minutes insulation (60 minutes integrity and insulation in certain glazing systems/dimensions - consult manufacturer). Pyrobel 17N60 minutes' integrity/ low radiation glass. Pyrobel 19H30 minutes integrity/ 30 minutes insulation. Horizontal glazing applications. Pyrobel 2560 minutes integrity/ 60 minutes insulation. Pyrobel 28H60 minutes integrity/ 60 minutes insulation. Horizontal glazing applications. Pyrobel 3090 minutes' integrity/ 90 minutes' insulation. Pyrobel 53N120 minutes integrity/ 120 minutes insulation. Pyrobel 54120 minutes' integrity/ 120 minutes' insulation. |
Grade | ExternalInternal |
Size | Larger expanses of glazing are possible with Pyrobel Visionline; consult manufacturer for all permissible sizes. |
Product Options | Size: Consult manufacturer for maximum tested glazing dimensions and approved glazing systems. |
