Pre-Assembled Zamak Drive Fixings - Hammer-in
Verified by manufacturer 6 months ago
Preassembled drive fixings for use in a range of substrates.
Application
Suitable for connections into:
- Concrete.
- Solid brick.
- Solid stone.
Partially suitable for connections into honeycomb brick.
Description
Preassembled drive fixings for use in a range of substrates.
General information
Color | Silver |
Finish | Zinc plated |
Material | Aluminium Other Guidance for specification option: Zamak. |
Shape | Circle |
Length | 30 mm 40 mm 50 mm 65 mm |
Width | 6 mm |
Uniclass | |
CAWS | E11/530 Fixings to concrete/ masonry substrate Z20/340 Masonry fixings Z20/340 Masonry fixings |
Specification data - Hammer-in fasteners
Core material | Steel class 6.8. |
Finish | Core: White zinc-plated. |
Body material | Zamak.Guidance for specification option: Zinc-aluminium alloy. |
Anchor length | 30 mm (7770000603000).Guidance for specification option: Pack size: 200. 40 mm (7770000604000).Guidance for specification option: Pack size: 100. 50 mm (7770000605000).Guidance for specification option: Pack size: 100. 65 mm (7770000606500).Guidance for specification option: Pack size: 100. |
Thread diameter | 6 mm. |
