Pilkington Optiphon™ Clear
Clear float glass for use in single glazing or insulating units.
Pilkington Optiphon™ is the brand name for the Pilkington laminated glass range.
Formed with a special acoustic pvb interlayer for enhanced sound insulation performance allowing thinner and lighter glass for the equivalent acoustic performance, which provides an alternative to secondary glazing.
Impact safety: 6.8 mm thickness provides minimum Class B performance to BS 6206:1981, BS EN 12600 Class 1.
Can be used in single or insulating units when it can be incorporated with Pilkington K Glass™ as the inner layer in an insulating glass unit which complies with Approved Document L (England & Wales) and Section 6 (Scotland).
| Size | As drawing ___ As window schedule ___ |
| Color | Clear |
| Features | Thinner and lighter for equivalent acoustic performance |
| Material | Float glass, PVB |
| Uniclass 2015 | |
| CAWS | H10/10 Patent glazing H10/115 Patent glazing H11/110 Curtain walling H13/115 Structural glass assembly L10/10 Wood windows L10/15 Wood windows L10/20 Steel windows L10/210 Wood windows L10/25 Aluminium windows L10/250 Wood windows L10/260 Wood windows L10/30 PVC-U windows L10/31 PVC-U windows L10/310 Steel windows L10/315 Steel windows L10/33 Proprietary windows L10/330 Aluminium windows L10/335 Aluminium windows L10/350 PVC-U windows L10/360 PVC-U windows L10/380 PVC-U windows L10/390 Proprietary windows L10/400 Composite windows L10/410 Composite windows L10/45 Rooflights L10/460 Rooflights L10/480 Roof windows L10/50 Roof windows L10/510 Glazed wood screens L10/550 Glazed metal screens L10/56 Glazed screen system L10/560 Glazed screen system L10/58 Secondary glazing system L10/580 Secondary glazing system L20/20 Wood flush doors L20/230 Wood flush doors L20/25 Wood panelled doors L20/250 Wood panelled doors L20/280 Doors L20/410 Wood doorsets L20/420 Wood doorsets L20/430 Wood doorsets L20/480 Doorsets L20/55 Doorsets L40/210 Putty-fronted single-glazing L40/230 Bead-fixed single-glazing L40/250 Bead-fixed single-glazing L40/260 Bead-fixed single-glazing L40/310 Bead-fixed single-glazing L40/330 Bead-fixed single-glazing L40/350 Bead-fixed single-glazing L40/370 Bead-fixed insulating glass units L40/371 Bead-fixed insulating glass units L40/372 Bead-fixed insulating glass units L40/380 Bead-fixed insulating glass units L40/381 Bead-fixed insulating glass units L40/40 Putty-fronted single-glazing L40/410 Single-glazing into grooves L40/430 Single-glazing into grooves L40/450 Single-glazing into grooves L40/470 Zipper gasket glazing L40/490 Single-sided gasket glazing L40/50 Bead-fixed single-glazing L40/530 Internal tape glazing L40/55 Bead-fixed insulating glass units L40/57 Bead-fixed insulating glass units L40/58 Bead-fixed insulating glass units L40/90 Internal tape glazing |
| Product Reference | Pilkington Optiphon™ Acoustic Laminated Glass |
| Type | ClearPatterned |
| Size | As drawing ___As window schedule ___ |
| Thickness (3 ply configuration) | 6.88.810.812.816.8 |
| Product Options | Maximum size:
Minimum size: 300 x 300 mm. |
| Platform | Compatible | Version | Certified to |
|---|---|---|---|
 IFC | IFC2X3 | 1 | 1.3 |
 Revit | Revit 2016 | 2 | 2.0 |
