PFC Corofil Cavity Fire Stop CCFS

Name: PFC Corofil Cavity Fire Stop CCFS
Brand: PFC Corofil Fire Stop Products
SKU: m5ZjqKQ6JQ21sQAUorjPGz

Verified by manufacturer 2 months ago

PFC Corofil Fire Stop Products

Third party certifications:

UL-EU Certified
Certificate type

Full fill cavity barrier designed to be installed within building cavities between the façade and the inner structure.

Jump to:

+44 (0)20 8391 0533 Website

Application

PFC Corofil Cavity Fire Stop CCFS has been designed and tested to be installed within building cavities between the façade and the inner structure. It can be installed against SFS with a calcium silicate fibre cement board and masonry substrates in both horizontal and vertical orientations, and is suitable for cavity widths up to 600mm. PFC Corofil Cavity Fire Stop CCFS can also be installed in a masonry support system in cavities up to 450mm wide.

Description

PFC Corofil Cavity Fire Stop CCFS is cut to size to suit the cavity width and can be supplied as plain stone wool, foil encapsulated, or with an integral DPC. PFC Corofil Cavity Fire Stop CCFS has been tested to EN1366-4 and EN1363-1 TR031 and will provide up to 120 minutes fire integrity and insulation performance.

Features and benefits:

• Suitable for cavities up to 600mm

• Can be installed against SFS with a calcium silicate fibre cement board

• Can be installed against aerated concrete, concrete and masonry substrates

• Can be installed in a masonry support system

• Provides fire resistance performance of up to 120 minutes integrity and insulation

• 3rd party certification; UL-EU Certificate UL-EU-01231-CPR

General information

Material	Stone wool Guidance for specification option: High density rock mineral fibre.
Shape	Rectangle
Length	1000 mm
Width	Bespoke
Height	82 mm 100 mm

Uniclass	Pr_25_80_81_51 Mineral wool fire-stoppingPrimary
CAWS	P10/40 Insulation fitted betweenor to the face ofstuds P12/360 Mineral wool rigid batts P12/40 Mineral wool rigid batts

Product range	Cavity Barriers

Specification data - Mineral wool fire-stopping

Material	-
Type	Semi-rigid.
Fire performance	Up to two hours (120 minutes). Guidance for specification option: To EN 1366-4 and EN 1363-1 TR031.

Cavity size	Guidance for specification option: Available to suit cavity widths up to 600 mm.
Third-party certification	UL-EU Certificate: UL-EU-01231-CPR.
