Intelligent liquid applied airtight air barrier - vapour control membrane. Spray, rolled or paint brush applied. Passivhaus airtightness membranes. AVCL membrane for airtightness
Passive Purple: The World's Leading Airtight Liquid Vapour Control
In the realm of modern construction, airtightness and vapor control are paramount for achieving energy efficiency and maintaining healthy indoor environments. At Intelligent Membranes, we are proud to introduce Passive Purple, the world's leading airtight liquid vapor control solution that sets a new standard for performance, versatility, and sustainability.
What is Passive Purple?
Passive Purple is an innovative liquid-applied membrane designed to create a seamless and airtight barrier. It prevents air leakage, reduces drafts, and controls moisture, significantly contributing to the energy efficiency of buildings. This advanced product is ideal for both new construction and retrofit projects, delivering exceptional airtightness without compromising on breathability.
Key Benefits of Passive Purple
Why Choose Passive Purple?
Passive Purple is the ultimate solution for those seeking to achieve airtightness and vapor control in their construction projects. Its seamless application, versatility, and eco-friendly attributes make it the preferred choice for architects, builders, and contractors worldwide.
Explore more about Passive Purple and other groundbreaking products at Intelligent Membranes. We're committed to providing innovative solutions that drive energy efficiency, sustainability, and comfort in every building. Let us help you create airtight structures that meet the highest standards of performance and durability.
A BBA-certified, Passivhaus Certified, ICC Certified airtight vapour control air barrier coating that is applied with an airless spray device on all areas of an external envelope (warm side of the insulation) of a building. This includes those difficult connection areas to the floor, wall, roof and joist. When used on the warm side of the insulation, it can be applied to either face of the external envelope. To install, ensure the material or surface is dust-free.
Features and benefits:
Technical characteristics:
- Adhesion (to ISO 4624):
Also classed as a radon barrier protection.
Color | Purple Green Blue Red Orange |
Finish | Other |
Material | Polymer |
Shape | Formless |
Length | Bespoke |
Width | Bespoke |
Height | Bespoke |
Warranty description | Lifetime |
Uniclass | |
CAWS | J41/395 Air and vapour control layer J42/395 Air and vapour control layer J21/395 Air and vapour control layer J31/330 Air and vapour control layer H30/261 Air and vapour control membrane H31/261 Air and vapour control membrane H11/785 Air and vapour control layer P10/60 Air and vapour control layer P10/310 Air and vapour control layer H30/30 Air and vapour control membrane |
Product range |
Material | Polymer. |
Purpose | Airtight vapour control membrane. |
Standard | To BS EN 12114, BS EN ISO 12572, BS EN ISO 15105 and BS EN ISO 4624. |
Third-party certification | British Board of Agrément (BBA), EOTA TR008 and PASSIVHAUS certified. |
Performance characteristics | |
Tensile strength (minimum) | 42 N/50 mm². |
Tear resistance | Manufacturer guidanceTo EOTA TR008, no cracking or delamination. |
Elongation to break | 350.5% and 325.2%.Guidance for specification option: Average and average after ageing respectively. |
Resistant to underground gases | Radon, Methane.Guidance for specification option: Radon diffusion coefficient (to K124/02/95): 3.3 x 10^-12. See Passive Purple Radon Certificate (linked) for further details. |
Water vapour resistance (minimum) | TO EN ISO 12572, 20–35 mm (0.3–0.5 mm resistance factor G-Value 100 MN-s/g) (0.3–0.5mm dry film thickness) G-value humidity variable: 4 MN-s/g. |
Fire performance | Class C-S1, d0. |
UV stabilization | Manufacturer guidanceConsult manufacturer. |
Anti-static properties | Manufacturer guidanceManufacturer's standard. |
Environmental performance requirements | |
Environmental rating | Passivhaus certified score of 0.03 ACH. |
Volatile organic compounds (VOC) emissions level (maximum) | Zero. |
Recycled content | Manufacturer guidanceGrinded as solid film in plastics. |
Form | Liquid. |
Root inhibitor | Manufacturer guidanceConsult manufacturer. |
Physical properties | |
Colour | Purple.Red.Green.Blue.Orange. |
Weight (minimum) | 10 kg. |
Dimensions | |
Thickness (minimum) | 0.5–1 kg/m² (500–1000 µm) 0.5–1 mm. |
Width (minimum) | 8–13 m².Guidance for specification option: Average. |
Roll length (minimum) | 8–13 m².Guidance for specification option: Average. |
Air tightness | 0.05 m³/h·m. Guidance for specification option: Airtightness floor/ wall after ageing (to NBN EN 12114 Eurocode 7). (50 BAR) (V). |
Sd value | 0.8–40 m. Guidance for specification option: Sd value humidity variable (to BS EN ISO12572). |
Methane permeability | 62–75 cm³. Guidance for specification option: To IOS 15105. (STP, mm.m²/day·atm). |
Contains Red List materials | No |
Country of material origin | Europe |
Country of product manufacture | Europe |
Material | Polymer |
Embodied carbonA1-A3 (production stage) as defined in BS EN 15804 | 0.09 kg CO₂ eq/unit |
Recyclability | Not recyclable due to its adhesion to other products |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 0 % Guidance for specification option: Grinded as solid film in plastics. |
