Application

Used with Paula Rosa Manhattan's handled range of kitchen furniture. For installation in domestic family kitchens.

Description

Panels can be the same color as the door or carcass. Infills must be in the same colour as the doors.


Features and benefits:

  • Versatile customization: Tailor your kitchen to your vision with our diverse range of customizable panels, allowing you to express your individual style.
  • Premium materials: Crafted with high-quality materials, our panels are built to withstand the rigors of daily use while maintaining their lustrous appearance.
  • Seamless integration: Achieve a cohesive look in your kitchen by seamlessly integrating our panels with various appliances, cabinets, and surfaces.
  • Personalized finishes: Choose from a variety of finishes, including the sleek allure of matte, the reflective brilliance of gloss, or the personalized charm of painted options.

General information

Color

Grey

White

Beige

Blue

Green

Manufacturer guidance

Please see specification data for further information.

Finish

Matt

Gloss

Painted

Material

Timber

Wood

Shape

Rectangle

Length

18 mm

Width

650 mm

Height

950 mm

1970 mm

2150 mm

2330 mm

Warranty description

Five year

Uniclass

Pr_40_30_87_42 Kitchen drawer unitsPrimary

CAWS

N11/10 Fitted base units and wall units

N11/320 Fitted wall units

N11/310 Fitted base units

Specification data - Kitchen drawer units

Form

Frontals.

Dimensions

650 x 950 x 18 mm.

650 x 1430 x 18 mm.

650 x 1970 x 18 mm.

650 x 2150 x 18 mm.

650 x 2330 x 18 mm.

Manufacturer guidance

Width x Height x Depth

Surface finishes

-

Manufacturer guidance

A range of colours and designs are available. See Paula Rosa Manhattan literature or consult with the manufacturer and insert requirements.

Doors

-

Material

MFC.

Finish and colour

Porcelain white.

Cashmere.

Light grey.

Dust grey.

Grey bardolino oak.

Sustainability data

Country of product manufacture

United Kingdom

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

57 %

Guidance for specification option:

Cabinets are made from chipboard that has a recycled content of approximately 57%. There are some frontal decors that are manufactured from 100% or 90% recycled chipboard; and selected frontals that have a 70% recycled PET foil, made from used plastic bottles. Please see manufacturer's sustainability literature for more information. Figures based on 2023 data.

BIM objects

BOS

NBS BIM Object Standard

This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.

Find out more about the NBS BIM Object Standard.

Platform Compatible Version
Revit
-

1

IFC
-

1
