Drawer Unit - Single Drawer

Verified by manufacturer 3 months ago

Paula Rosa Manhattan

720 mm high single drawer units available in 500, 600, 800, 900, and 1000 mm widths.

Jump to:
BOS
+44 01903 524 300 Website

Application

Used with Paula Rosa Manhattan's handled range of kitchen furniture. For installation in domestic family kitchens.

Description

Single drawer unit – where functionality meets elegance in a seamless design. Elevate your kitchen organization with these thoughtfully crafted units, offering a perfect blend of style and convenience in a singular, sophisticated drawer.


Features and benefits:

  • Efficient organization: Maximize your kitchen space with a single drawer that provides organized storage for utensils, cutlery, or any essentials you need close at hand.
  • Sleek design aesthetics: Immerse your kitchen in modern sophistication with a streamlined, minimalist design that complements any culinary space.
  • Durable construction: Crafted with precision and durability, the single drawer units are built to withstand daily use while maintaining their refined appearance.
  • Soft-close mechanism: Experience a touch of luxury with a soft-close mechanism, adding a quiet and elegant functionality to your kitchen.

General information

Color

Grey

White

Beige

Manufacturer guidance

Please see specification data for further information.

Finish

Matt

Material

MFC

Melamine

Shape

Rectangle

Length

568 mm

Width

500 mm

600 mm

800 mm

900 mm

1000 mm

Height

720 mm

Warranty description

Five year

Uniclass

Pr_40_30_87_42 Kitchen drawer unitsPrimary

CAWS

N12/420 Cupboards and storage units

N12/420 Cupboards and storage units

N11/310 Fitted base units

N11/10 Fitted base units and wall units

N11/320 Fitted wall units

Specification data - Kitchen drawer units

Form

Base units.

Dimensions

500 x 720 x 568 mm.

600 x 720 x 568 mm.

800 x 720 x 568 mm.

900 x 720 x 568 mm.

1000 x 720 x 568 mm.

Manufacturer guidance

Width x Height x Depth

Surface finishes

-

Manufacturer guidance

A range of colours and designs are available. See Paula Rosa Manhattan literature or consult with the manufacturer and insert requirements.

Doors

-

Finish and colour

Porcelain white.

Cashmere.

Light grey.

Dust grey.

Grey bardolino oak.

Side panels, plinths and pelmets

-

Material

MDF.

MFC.

Finish and colour

Porcelain white.

Cashmere.

Light grey.

Dust grey.

Grey bardolino oak.

Sustainability data

Country of product manufacture

United Kingdom

Recyclability

Recyclable

Guidance for specification option:

Each component of our furniture can be recycled at the end of its lifetime, if disposed of correctly.

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

57 %

Guidance for specification option:

Cabinets are made from chipboard that has a recycled content of around 57%. There are some frontal decors that use 100% recycled chipboard; see manufacturer's sustainability literature for more information.

BIM objects

BOS

NBS BIM Object Standard

This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.

Find out more about the NBS BIM Object Standard.

Platform Compatible Version
Revit
-

1

IFC
-

1
