Outsulation®

Outsulation®

Third party certifications:
  • BBA Agrément Certificate

    BBA Agrément Certificate

    Certificate type

  • QA Certificate

    QA Certificate

    Certificate type

Dryvit – a brand of CPG UK Ltd

A polymer-based barrier external wall insulation system incorporating EPS 70E grade expanded polystyrene (EPS) insulation.

Jump to:
+44 (0)1462 819555 www.dryvit.co.uk
Description

Dryvit’s Outsulation is a cost effective external wall insulation(EWI) suitable for use on either new construction or refurbishment projects. The system is based on a simple premise – insulation is more effective when placed on the exterior of a building. By bringing insulation to the outside of external walls, this barrier EWI eliminates thermal bridges; reduces air, wind and moisture penetration through the system; stabilises interior environments and minimises thermal shock.

Benefits:

  • Design freedom. The system can be installed over a variety of substrates. Expanded polystyrene (EPS) insulation is lightweight and can be cut or grooved to various shapes and surface patterns.
  • Energy efficiency. Outsulation enables new or existing buildings to meet strict energy efficiency requirements. Heating or cooling costs are demonstrably lower in lieu of other exterior materials.
  • Weatherability. Dryvit EWI are formulated to provide the utmost in weather protection, providing a resilient barrier against the elements.
  • Durability. The combination of system components provides unsurpassed long-term durability meeting design requirements for use in virtually any location.
  • Aesthetics. Dryvit finishes are available in a wide array of textures in both standard and custom colours. Their speciality finishes enable designers to replicate a variety of real stone or brick finishes from limestone to granite at a fraction of the cost.
  • Cost effective. Outsulation is easily adapted to complex project details. Installation is rapid, and routine maintenance is minimal.
  • Testing. Independently certified by BBA and other international test bodies. Dryvit manufacturing plants are ISO 9001: 2000 certified, demonstrating the highest standards of quality and consistency.

General information

Finish

FDPMR

Acrylic textured finish.

HDP

Silicone based technology textured finish.

PMRB

Acrylic textured finish.

Uniclass 2015

Ss_25_45_72_02 Adhesive-fixed external wall insulation systemsPrimary

CAWS

M21/20 External wall insulation system

M21/210 External wall insulation system

Specification data - Adhesive-fixed external wall insulation systems

Product Reference

Outsulation®

Insulation

-

Method of fixing

Dryhesive™ Plus

Dryflex

Polymer-based, water-resistant base coat and adhesive.

Finish

FDPMR

Acrylic textured finish.

HDP

Silicone based technology textured finish.

PMRB

Acrylic textured finish.

Texture

Freestyle

Lymestone

Quarzputz 2 mm aggregate

FDPMR, HDP and PMRB finishes.

Sandblast 1 mm aggregate

PMRB finish.

Sandpebble 1.5 mm aggregate

FDPMR, HDP and PMRB finishes.

Sandpebble fine 1 mm aggregate

HDP, FDPMR and PMRB finishes.

Colour

Refer to standard colour range for details and insert requirements.

Fire barrier

Not required

Mineral wool lamella

High performance mineral wool lamella for receiving Dryvit base coats and finishes.

Accessories

Not required

Mouldings

Extensive range available, consult manufacturer for details.

Standard product features

Insulation:

  • Type: Expanded polystyrene boards (EPS) grade 70E
  • Method of fixing: Genesis adhesive and/ or mechanical fixings in accordance with manufacturer's recommendations.

Reinforcement:

Standard Plus – Glass Fibre. Panzer 20 and standard plus mesh to areas subject to high impact.

Detailing mesh:

Dryvit detail mesh suitable for back wrapping EWI at termination details, forming reveals, masking Fire barriers prior to placing general reinforcing mesh, forming groove details.

Beads/ Trims:

Dryvit Aluminium Starter Track to thickness of insulation mechanically fixed with suitable hammer head or self-tapping fixings to base of system.

Product Options

Pretreatment:

Consult with Dryvit for details of preparation to suit project substrate. Use fungicidal wash by system manufacturer. If required, specify in 'Structural substrate' clause.

Insulation:

Method of fixing: Dryhesive™ Plus adhesive and/ or mechanical fixings in accordance with manufacturer's recommendations.

Finish:

  • FDPMR: Premixed 100% acrylic finish containing DPR and PMR technology as well as a film forming accelerator for improved resistance to wash off.
  • HDP: Proprietary, silicone based technology textured finish which promotes hydrophobicity enhancing reduced dirt pick up properties.
  • PMRB: Aggregate textured 100% acrylic-based proven mildew (PMR) and dirt pick resistance (DPR) finish.

Brick effect finish or other from speciality finish range are also available, consult with manufacturer for details.

Accessories:

  • Dryvit drainage strip.
  • Expansion/ movement joints: Will be required to reflect such joints in the existing wall plus any movement joints to reduce the risk of cracking in the render finish. Consult with Dryvit for recommendations for type and location.

Fire barrier:

Position fire barriers in accordance with Building Control Officers requirements. Barriers to be adhesively fixed with Dryvit Detail Mesh.

Third party certifications
  • 98/3548
  • European Technical Approval (ETA): 10/0101
