Optima® XPC 250 mm (Extruded Plank Rainscreen)

Application

Robust design can be secret-fixed, horizontally, vertically or diagonally.

Description

Robust secret fix extruded aluminium plank system available in different standard widths , comprising a 6063 T6 extruded plank panel, XPC carrier rails 'T&L' and adjustable helping hands brackets.


Features and benefits:

  • Adjustable brackets.
  • Also available in different standard widths: 150 mm, 200 mm and 225 mm (specified separately).
  • Recessed or hairline appearance.
  • Seamless integration.
  • CWCT-certified and approved.
  • Compliant to NHBC requirements.


Sotech would be please to discuss any bespoke detail proposals.

General information

Finish

PPC

Andonized

Material

Aluminium

Shape

Rectangular

Flat plank system with optional castellated profile.


Size

250 x 6400 mm

Width x maximum length.

WarrantyDescription

Dependent on specified finish and location, consult manufacturer.


-

Uniclass 2015

Pr_25_71_14_02 Aluminium cassette panelsPrimary

CAWS

H92/120 Rainscreen cladding

Specification data - Aluminium cassette panels Enhanced data

Alloy

-

Grade

6063 T6.

Sheet thickness

15 mm.

Panel size

250 x 6400 mm.

Maximum length 6400 mm, insert requirements.

Finish

-

Material

Polyester powder-coated.

Anodized.

Colour

Insert guidance. All PPC and Anodized finishes available.


Environmental information

Recyclability

Prime aluminium.


-

Recycled content

99

Digital objects

Platform Compatible Version Certified to
IFC
-

1

2.1
Revit
-

1

2.1
Download now from NBS National BIM Library
