Nordic Vinyl Tile Collection: Nordic 5.0 Tile 4377V

Verified by manufacturer 5 days ago

Honey 77103

Shaw Contract Variant:

Heavy commercial luxury vinyl tile (LVT) with fiberglass.

Jump to:
+44 (0) 20 79614120 Website

Application

Suitable for commercial interiors.

Recommended installation methods (product specific):

  • Brick;
  • Ashlar;
  • Herringbone;
  • Stagger.

Description

Heavy commercial luxury vinyl tile (LVT) with fiberglass, available in 10 colours.

Features and benefits:

  • CE marked.
  • UKCA marked.
  • Declaration of Performance (DoP): UK.DOP/0321/CPR/1222/1222/LVT.
  • Use classification 33 Commercial Heavy to BS EN ISO 10874.
  • FloorScore® certified and EPD available.
  • 15-year commercial limited warranty.
  • Electrostatic propensity rating of ≤2.0 kV (to EN 1815).
  • Adhesive-free installation: IOBAC MagTabs™.
  • Contributes towards LEED and WELL credits.

Please note: Colour and visual variation is inherent on all modular products. Consult manufacturer's datasheet for further details.

General information

Color

Brown

Beige

Finish

Other

Guidance for specification option:

ExoGuard+®.

Material

Vinyl

PVC

Fiber-glass

Shape

Rectangle

Length

1219.2 mm

Width

184.2 mm

Height

5.1 mm

Warranty description

15 year

Uniclass

Pr_35_57_71_68 Polyvinyl chloride (PVC) tilesPrimary

CAWS

M50/110 Resilient floor tiling

M50/10 Resilient floor tiling

SKU Code

4377V

Specification data - Polyvinyl chloride (PVC) tiles

Classification data

Product reference

Nordic Vinyl Tile Collection: Nordic 5.0 Tile 4377V.

Standard

To BS EN ISO 10874.

Use class

To BS EN ISO 10874, Class 33.

Slip potential

-

Slip resistance value (SRV) (minimum)/ pendulum test value (PTV) (minimum)

To BS 7976-2, 59/ 37 dry/ wet.

Guidance for specification option:

To DIN 51130, R9 (shod ramp).

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

0%.

Size

1219.2 x 184.2 mm.

Thickness

5.1 mm.

Colour and pattern

Honey 77103.

Surface finish

ExoGuard+®.

Mass

9.17 kg/m² (total mass).

Guidance for specification option:

Weight per box: 17.18 kg.

FlammabilityRating

To EN 13501-1, Bfl-S1 (unadhered testing).

Thermal resistance

To ISO 8302, 0.018 m² K/W.

Castor chair rating

To EN 425, ISO 4918, No damage.

Impact sound reduction

To BS EN ISO 10140, ΔLw 9 dB/ 21 dB with 2 mm underlay.

Colour fastness

To BS EN ISO 105-BO2, 7/8.

Light reflectance

26.8.

Dimensional stability

To EN ISO 23999, ≤0.15%.

Third-party certification

FloorScore® and Environmental Product Declaration (EPD).

Sustainability data

Country of material origin

China

Material

Vinyl
PVC
Fiber-glass
Carbon dioxide equivalent

Carbon dioxide equivalent, as defined in BS EN 15804

Self-declared

Stage
Normalised unit (kg CO₂ eq/kg)
Declared unit (kg CO₂ eq/m²)
Stage:A1–A3 ('Production stage')
Normalised unit :
Declared unit : 9.75

Lower emissions

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

0 %
