MEDITE TRIMAX Double Shiplap - Cladding

Verified by manufacturer 4 days ago

MEDITE SMARTPLY

Modified wood board decorative cladding with shiplap profile.

Jump to:
+44 (0)1322 424900 Website

Application

Suitable for external cladding.

Description

MEDITE TRIMAX is crafted from MEDITE TRICOYA EXTREME (MTX), a high-performance panel product used for its durability and stability in demanding environments. MTX makes MEDITE TRIMAX a suitable cladding solution with a selection of finishes.

MTX is manufactured using a wood treatment process that enhances its durability and stability. The acetylation process modifies the wood at a molecular level, making it more dimensionally stable to variations in temperature and humidity. This process also makes the wood more durable, as it prevents the material from being easily broken down. Acetyl groups, which are naturally found in all wood species, are added to the wood during this process, ensuring no harmful chemicals or toxins are introduced. Unlike traditional treatments that only improve durability, this process enhances the wood’s stability throughout, offering a product that lasts longer and performs better in various conditions.

Features and benefits:

  • Durable with 50 year guarantee on the substrate.
  • Reduced swelling and shrinking.
  • Low maintenance.
  • Sustainable material - manufactured from FSC certified forests.
  • Supplied fully finished or primed.
  • Shiplap edges.

General information

Color

Grey

White

Finish

Primed

Painted

Material

Wood

Shape

Rectangle

Length

4880 mm

Width

194 mm

244 mm

294 mm

Height

12 mm

Uniclass

Pr_25_71_97_55 Modified wood weatherboardsPrimary

CAWS

H21/116 Horizontal timber weatherboarding

H21/115 Vertical timber weatherboarding

H21/10 Vertical timber weatherboarding

H21/111 Horizontal timber weatherboarding

H21/110 Vertical timber weatherboarding

H21/15 Horizontal timber weatherboarding

Specification data - Modified wood weatherboards

Classification data

Standard

To EN 13986.

Reaction to fire classification

E-s2,d0.

Release of dangerous substances

E1.

Thermal conductivity

0.101 W/m–K.

Biological durability

-

Standard

To EN 13986.

Use class

BS EN 335, Class 1.
BS EN 335, Class 2.
BS EN 335, Class 3.
BS EN 335, Class 4.

Profile

Shiplap.

Finished size

-

Face width

194 mm.
244 mm.
294 mm.

Thickness

12 mm.

Applied finish

Primed, Silk Grey RAL 7044.
Fully finished, Traffic White RAL 9016.
Fully finished, Anthracite Grey RAL 7016.
Fully finished, Silk Grey RAL 7044.

Length

4880 mm.

Bond

0.65 N/mm².

Guidance for specification option:

Internal bond.

Thermal resistance

0.114 m²·K/W.

ThicknessSwelling

2%.

Guidance for specification option:

24 hours.

Sustainability data

Country of product manufacture

Ireland

Material

Wood

Literature

PPG Coatings Datasheet

PPG Coatings Datasheet

MEDITE TRIMAX Declaration of Performance

MEDITE TRIMAX Declaration of Performance

MEDTE TRIMAX Product Datasheet

MEDTE TRIMAX Product Datasheet

MEDITE TRIMAX Technical Guide v2

MEDITE TRIMAX Technical Guide v2
