Description

Pressed aluminium stepped profile gutter system.

  • Range of section sizes.
  • Direct fix to fascia through prepunched slots at 600 mm centres (through flat back of gutter) using 25 mm x 12 gauge stainless steel screws.
  • Jointing: External joint strap assembled dry, with gap for expansion. Joint finished internally with silicone sealant. No visible bolts through sole at joints.
  • Powder coated finish applied in-house. Consult manufacturer for choice of colour. Thirty year guarantee available on application, subject to location.
  • Compatible downpipes listed separately.

General information
Finish

Anodized, colour ___

Nonstandard option.

Interpon D, colour ___, gloss level ___

Polyester powder coating. Standard option.

___ Powder coating, colour ___, gloss level ___

Non standard option.

PVDF, colour ___

Nonstandard option.

Uniclass 2015
External gravity rainwater drainage systems (Ss_50_30_02_28)Primary
Specification data - External gravity rainwater drainage systems
Product Reference

Lindisfarne Gutter

Layout

As drawing ___

Section (nominal depth x width)

85 x 110 mm

External dimensions 85 x 110 mm. Gauge 1.6 mm.

108 x 135 mm

External dimensions 110 x 135 mm. Gauge 2 mm.

140 x 175 mm

External dimensions 144 x 175 mm. Gauge 2 mm.

175 x 210 mm

External dimensions 177 x 210 mm. Gauge 2.5 mm.

Outlet

63 mm diameter

76 mm diameter

102 mm diameter

Not available on section 85 x 110 mm.

72 x 72 mm

102 x 102 mm

Not available on sections 85 x 110, 108 x 135 mm.

Finish

Anodized, colour ___

Nonstandard option.

Interpon D, colour ___, gloss level ___

Polyester powder coating. Standard option.

___ Powder coating, colour ___, gloss level ___

Non standard option.

PVDF, colour ___

Nonstandard option.

Other requirements

External angle 90 º

Gutter length (internal faces): 75 mm, each face.

Internal angle 90 º

Gutter length (external faces): 75 mm, each face.

External angle 135 º

Internal angle 135 º

External angle ___ º

Internal angle ___ º

External joint strap

Stop end left

Gutter length: 35 mm.

Stop end right

Gutter length: 35 mm.

Standard product features

Plain gutter length:

3 m.

Running outlet length:

250 mm.

Finish:

–Standard polyester powder coating: Interpon D1036, standard colour range.

  • Electrostatically applied to BS EN 12206 and Qualicoat Class 1 standards.
  • Compliant to ECHA standards which includes Chrome Free solution.
  • Film thickness: 60µ (minimum 50µ).

Product Options

Indicative flow rates (maximum, with central outlet):

Roof areas are indicative maxima. Suitable outlet interval varies with local climate and other factors. Consult manufacturer.

– Gutter size 85 x 110 mm. Flow rate: 1.68 L/s.

  • Outlet size 63 mm diameter. Flow rate: 2 L/s. Roof area: 96 m².
  • Outlet size 76 mm diameter. Flow rate: 2.7 L/s. Roof area: 137 m².
  • Outlet size 72 x 72 mm. Flow rate: 2.9 L/s. Roof area: 147 m².

– Gutter size 108 x 135 mm. Flow rate: 2.96 L/s.

  • Outlet size 76 mm diameter. Flow rate: 3.2 L/s. Roof area: 162 m².
  • Outlet size 72 x 72 mm. Flow rate: 3.4 L/s. Roof area: 172 m².

– Gutter size 140 x 175 mm. Flow rate: 5.73 L/s.

  • Outlet size 76 mm diameter. Flow rate: 3.7 L/s. Roof area: 188 m².
  • Outlet size 102 mm diameter. Flow rate: 6.6 L/s. Roof area: 335 m².
  • Outlet size 72 x 72 mm. Flow rate: 4 L/s. Roof area: 203 m².
  • Outlet size 102 x 102 mm. Flow rate: 8 L/s. Roof area: 406 m².

– Gutter size 175 x 210 mm. Flow rate: 9.85 L/s.

  • Outlet size 102 mm diameter. Flow rate: 7.6 L/s. Roof area: 386 m².
  • Outlet size 102 x 102 mm. Flow rate: 9.3 L/s. Roof area: 472 m².
