INTRAgrille

Name: INTRAgrille
Brand: INTRAsystems
SKU: rCdiM24Ft7ZDJTmmqR9VBt

Verified by manufacturer 2 months ago

INTRAsystems

Third party certifications:

ISO 9001 Quality Management
Certificate type

A superb example of engineered stainless steel. With a striking linear appearance, this versatile product provides a stunning architectural finish for applications where only the best will suffice.

Jump to:

BOS

+44 (0)1425 472000 Website

Application

Suitable for use in:

Ventilation/service trench covers
Interior and exterior drainage covers
Walkways & Stairtreads
Decorative Cladding/ wall features
Lighting covers

Description

Architectural stainless steel grille providing outstanding visual appearance for an extensive range of applications. It is bespoke manufactured and there are unlimited variables on profile size/ design, support profile and profile spacing. Radial and tubular designs are used to suit curved/ bespoke applications.

Features and benefits:

Architectural recessed stainless steel floor grilles.
Outstanding visual appearance.
Suitable for an extensive range of applications
Bespoke manufactured

General information

Color	Grey Red Blue Brown Purple Black Show more
Finish	Stainless steel
Material	Stainless steel Guidance for specification option: Stainless steel grade 304, 1.4301 or Stainless steel grade 316L, 1.4404.
Shape	Rectangle
Length	Bespoke
Width	Bespoke
Height	Bespoke
Warranty description	Ten year

Uniclass	Pr_25_71_42_70 Raised access floor panelsPrimary
CAWS	L30/30 Proprietary stairs L30/310 Proprietary stairs L30/45 Ramps/ walkways L30/460 Walkways N10/290 Matwell frames P31/370 Access covers/ gratings Q10/180 Drainage channel systems with gratings

Product range	Entrance Matting Systems

Specification data - Raised access floor panels

Casing	-
Material	Stainless steel grade 304, 1.4301. Stainless steel grade 316L, 1.4404.

Top triangular	18S. Guidance for specification option: Width: 1.5 mm, height: 2.5 mm, weight: 20 g/m. 22S. Guidance for specification option: Width: 1.8 mm, height: 3.7 mm, weight: 35 g/m. 28S. Guidance for specification option: Width: 2.2 mm, height: 4.5 mm, weight: 53 g/m. 40A. Guidance for specification option: Width: 3 mm, height: 6 mm, weight: 79 g/m. 42S. Guidance for specification option: Width: 3.4 mm, height: 6.8 mm, weight: 121 g/m.
Bottom support	Q35. Guidance for specification option: Width: 5 mm, height: 3 mm, weight: 65 g/m. Q53. Guidance for specification option: Width: 3 mm, height: 10 mm, weight: 210 g/m. 25 x 3. Guidance for specification option: Width: 3 mm, height: 25 mm, weight: 558 g/m. 35 x 3. Guidance for specification option: Width: 3 mm, height: 35 mm, weight: 793 g/m.
