Hudevad Niveau Lowline - Radiator
Verified by manufacturer 3 months ago
Type 44 Radiator
Type 44 Radiator
Wall or floor mounted radiator in steel with fixed casing and convectors.
Application
Wall or floor mounted radiator for internal application.
Description
A low radiator that is suitable for preventing cold draughts in front of large window surfaces. The radiator is simple in design and has an optimal size for placement under windowsills and will blend into its surroundings.
Features and benefits:
- Smooth front and back plate.
- A detachable top grille.
- Available in three different types.
- Closed sides.
- Danish design.
- Ten-year warranty.
General information
Color | White Guidance for specification option: White RAL 9016, gloss 70. Other |
Finish | Powder-coated |
Material | Steel |
Shape | Rectangle |
Length | 1000 mm 1100 mm 1200 mm 1300 mm 1400 mm |
Width | 104 mm 162 mm 220 mm |
Height | 200 mm |
Warranty description | Ten year |
Uniclass | |
CAWS | T90/465 Radiators T90/465 Radiators |
Specification data - Radiators
Standards | To BS EN 442-1 and BS EN 442-2. |
Radiator type | Quadruple panel double convector.Guidance for specification option: Type 44. |
Output | Guidance for specification option: Consult manufacturer and insert requirements. |
Finish | Powder-coated.Guidance for specification option: In accordance with DIN 55900, BS EN 442. |
Connections | Guidance for specification option: All connections 1/2” standard (adapters available). |
Accessories | Panel radiator feet.Lowline brackets.Danfoss RA-N valve.Not required. |
Heating element | To BS EN 442, steel panel. |
Colour | White RAL 9016, gloss 70. Guidance for specification option: Standard. Other. Guidance for specification option: Can be painted in other colours. Insert requirements. |
TestPressure | 13 bar. |
Operating pressure (maximum) | To BS EN 442, 10 bar. |
MaximumOperatingTemperature | 110°C. |
Height | 200 mm. |
Length | 1000–3000 mm. Guidance for specification option: In increments of 100 mm. Consult manufacturer's literature and insert requirements. Manufacturer guidanceAvailability of lengths varies depending of chosen tapping configuration and height. |
Depth | 220 mm. Guidance for specification option:
|
Tapping configuration | Tapping code 10. Guidance for specification option: Tapping type: ABCD (4 tap). Tapping code 11. Guidance for specification option: Tapping type: FF built-in valve (6 tap right). Tapping code 12. Guidance for specification option: Tapping type: EE built-in valve (6 tap left). |
Sustainability data
Contains Red List materials | No |
Country of material origin | Europe |
Country of product manufacture | Europe |
Recyclability | yes |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 95 % |
BIM objects
| Platform | Compatible | Version |
|---|---|---|
 Revit | - | 1 |
Literature
Hudevad Niveau Lowline
