HTM63 / HTM71 Base Unit

Verified by manufacturer 20 days ago

HSB50 Single base unit, on plinth - 500 mm wide

Benchmark Products Variant:

A range of base units for healthcare environments.

Jump to:
+44 (0)1953 889603 Website

Application

Suitable for healthcare environments.

Description

Purpose built HTM63 base units.


Features and benefits:

  • High quality.
  • Purpose built to requirements.
  • Factory fitted, complete with doors and accessories.
  • Delivered fully assembled, ensuring quality is maintained throughout the manufacture process.

General information

Color

Other

Guidance for specification option:

Colour from the Benchmark colour collection.

Finish

Laminated

Material

PVC

MFC

Medium density fibreboard (MDF)

Laminate

Shape

Rectangle

Length

Bespoke

Width

300 mm

350 mm

400 mm

450 mm

500 mm

Show more

Warranty description

Five year

Uniclass

Pr_40_30_87_46 Laboratory storage unitsPrimary

CAWS

N10/10 Purpose-made

N10/135 Storage and display units

Specification data - Laboratory storage units

Dimensions

-

Manufacturer guidance

Consult variants tab for details.

Material

Melamine Faced Chipboard (MFC).

Colour

-

Manufacturer guidance

Colour from the Benchmark colour collection.

Consult manufacturer for details and insert requirements.

Plinth

18 mm black melamine-faced moisture-resistant MDF.

Handles

Solid stainless steel ‘D’ type (non lacquered). 10 mm diameter, 160 mm centres.

Hinges

Hettich 270° exposed knuckle hinge.

Locks

Not required.

Hafele Symo 3000 rim lock (Hafele Symo 3000 rim lock. suited if required)

Exposed edges

2 mm PVC lipped.

Sustainability data

Contains Red List materials

No

Country of material origin

United Kingdom

Country of product manufacture

United Kingdom

Material

PVC

MFC

Medium density fibreboard (MDF)

Laminate

Manufacturing plant location

Expected Life

12 year
