HeartFelt® MultiPanel - Acoustic Ceiling Panel

Verified by manufacturer 1 day ago

30 x 60 mm Panels - 30HL60

Hunter Douglas Architectural Variant:
Product certifications:
  • Cradle to Cradle Certified

    Cradle to Cradle Certified

    Certificate type

  • EPD

    EPD

    Certificate type

  • Indoor Air Comfort – Eurofins

    Indoor Air Comfort – Eurofins

    Certificate type

HeartFelt® MultiPanel is a stylish, modular ceiling system that combines four different panel sizes.

Jump to:
+44 (0)1604 648229 Website

Application

Suitable for use internally in suspended acoustic ceiling applications.

Description

HeartFelt® MultiPanel ceiling panels provide a warm look combined with felts natural sound absorption. Available with different width and colour combinations to create new patterns that add variation to the interior ceiling.

Features and benefits:

  • Four box-shaped panels available: 30 x 60 mm, 80 x 35 mm, 130 x 35 mm and 180 x 35 mm.
  • All panels can be combined and mixed on the same carrier.
  • Outstanding acoustic performance.
  • Easy installation and low risk for damages.
  • Recyclable or easily reusable.
  • Easy to maintain: dirt and dust resistant.

General information

Color

Finish

Natural

Material

Felt

Aluminium

Shape

Rectangle

Length

1500 mm

Guidance for specification option:

Maximum carrier span.

Bespoke

Width

1200 mm

Guidance for specification option:

Maximum panel span.

Bespoke

Uniclass

Ss_25_25_75_05 Acoustic panel lining systemsPrimary

CAWS

K45/39 Infill units

K45/370 Infill units

K40/265 Infill units

K40/115 Unit/ modular suspended ceiling system

K40/10 Unit/ modular suspended ceilings

K13/170 Acoustic panel lining

K13/170 Acoustic panel lining

SKU Code

30HL60

Specification data - Acoustic panel lining systems

Classification data

Panelling

-

Type

30HL60.

Manufacturer guidance

Acoustic panel type.

Surface material

Non-woven, thermoformed polyester (PES) fibres.

Surface finish

Profiled.

Fasteners

Stabilization bracket and quick hanger.

System accessories

Not required.
Carrier splice.
Panel splice.
Endcap, 30HL60 panel.

Components

Profile, carrier, stabilization bracket and profile, quick hanger and wire hanger.

Profile

HeartFelt® MultiPanel.

Manufacturer guidance

Panel support profile.

Panel dimensions

30 x 60 mm.

Guidance for specification option:

Width x height.

Manufacturer guidance

Acoustic panel dimensions.

Open space

40%.

Manufacturer guidance

Openness in panel.

Weight

2.9 kg/m².

Sound absorption coefficient

αw, 0.6.

Joint

20 mm.

Colour

White 7593.
Light grey 7596.
Middle grey 7597.
Dark grey 7598.
Black 7594.
Creme 7575.
Light brown 7576.
Medium brown 7577.
Dark brown 7578.
Umber 7579.

Reaction to fire

To EN 13501-1, B-s1, d0.

Sustainability data

Material

Felt
Aluminium

A1-A3 (production stage)

Normalised unit

Declared unit

9.38 kg CO₂ eq/unit

Certified

Lower emissions

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

86 %

Guidance for specification option:

Suspension components only. 0% for felt components.

Product certifications

Product certifications

Cradle to Cradle Certified

Cradle to Cradle Certified

HeartFelt - Cradle to Cradle Certified Bronze

EPD

EPD

HeartFelt® MultiPanel - EPD

Indoor Air Comfort – Eurofins

Indoor Air Comfort – Eurofins

HeartFelt® - Indoor Air Comfort Gold

Literature

Heartfelt Colour Options

Heartfelt Colour Options

Heartfelt Multipanel - Datasheet

Heartfelt Multipanel - Datasheet

Installation-Instructions HeartFelt® Multi-Panel Ceiling-application_rv0

Installation-Instructions HeartFelt® Multi-Panel Ceiling-application_rv0
