Gullwing Shelter
Description

Gullwing shelters are ideal for covering seating areas or to provide cycle and motorcycle parking facilities. Shelters are supplied complete with integral guttering and the standard design can be modified to suit requirements. Features include two tubular supporting columns which are joined to the roof via a bolted spigot joint. The glazing support consists of two cruciform which are joined together with two 89 mm diameter steel bars. The glazing frame is suspended using 12 mm diameter steel bars. Two options are available for fixing, surface or base plate mounted.

General information

Uniclass 2015

Pr_20_65_78_58 Open sided sheltersPrimary

CAWS

B91/385 Shelter

Specification data - Open sided shelters

Product Reference

Gullwing Shelter

Frame finish

-

Type

Galvanized

Galvanized and powder coated

Zinc rich primer and powder coated

Colour

Not required

BS 00 A 05

Light grey.

BS 04 E 53

Poppy red.

BS 14 C 39

Brown.

BS 14 C 39

Brown.

BS 18 B 25

Dark grey.

BS 18 E 53

Blue.

RAL 9005

Black.

RAL 9016

White.

Cladding

PET, Clear

PET, Opal

PET, Smoked grey

Toughened glass

Fixing

Base plate

Surface mounted

Standard product features

Length:

Standard shelter: 8350 mm.

Height x width:

2841 x 3729 mm.

Frame:

Structural grade carbon steel.

Product Options

Cladding:

  • Polyethylene Terephthalate (PET), available in three finishes.
  • Toughened glass.
