GreenCoat® PLX Colour Coated Steel Traditional Fully Supported Batten Roll Roof And Facade Cladding, With/Without Solar - Traditional Batten Roll Cladding

Verified by manufacturer 4 months ago

Metal Solutions Limited Third party certifications:
  • EPD

    EPD

    Certificate type

  • R EACTION TO FIRE - CLASSIFICATION REPORT EUI-22-000041

    R EACTION TO FIRE - CLASSIFICATION REPORT EUI-22-000041

    Certificate type

  • ISO 9001 Quality Management

    Certificate type

  • ISO 14001 Environmental Management Systems

    Certificate type

  • IATF 169492016

    IATF 169492016

    Certificate type

Traditional fully-supported colour-coated steel batten roll roof and facade cladding.

Jump to:
+44 (0)1204 491800 Website

Application

Roofing and cladding.

Description

Steel batten roll for use as a roofing or cladding application. It is available in two finishes, Pro is a smooth finish and Pural offers a subtle dappled effect.

Pro (smooth finish) is the product to use when attaching thin film solar photovoltaics.


Features and benefits:

  • Manufactured from lightweight (350 g/m² zinc coated) corrosion resistant steel.
  • Material - A1 fire rated.
  • Ultraviolet (UV) light and scratch resistant.
  • GreenCoat® colour coated steel products from SSAB Swedish Steel use Swedish rapeseed oil in the coating, producing a sustainable colour coated steel for exterior buildings. The patented BT coatings (Bio-based Technology) offer environmental advantages (100% recyclable) and increased performance.
  • Can be utilized as a heritage roof covering system.
  • Solar specification also available for use with thin film solar photovoltaics. In this instance the PRO version must be used. Contact Metal Solutions for more information.
  • Suitable as a dormer roof and facade cladding finish.


Protective Finishes:

Greencoat steel is protected with a zinc coating before being finished with the final BT finish.

The zinc coating (Z, 100 – 350 g/m2) is lead free and has a

minimum zinc content of 99 %. This protects the steel from

corrosion in two ways. It is a protective layer keeping oxygen and water away from the steel, but it also acts as a cathodic protection. This means that at cut edges or in case of damages through the zinc coating, the zinc will sacrifice itself and react to form protective compounds and block further corrosion processes.


Substructure:

Suitable substructure materials:

  • Ventilated 18 mm-thick weather and boil proof (WBP) plywood.
  • Ventilated oriented strand board OSB3.
  • Composite panel.
  • Rigid insulation.
  • Profiled metal deck.


Underlay:

ISO-Mat Pro® underlay is recommended for cold roof applications.

ISO-Mat Metal® underlay is recommended for warm roof applications.

Available from:

roofing-tools.com


Clips:

TS 5 x 20 x 50 stainless steel fixing strip.

Available from:

roofing-tools.com


Installation:

Contact Metal Solutions for a list of Approved Installers available by postcode.

Email

gaynor@metalsolutions.uk.com

General information

Color

Brown

Grey

Red

Green

Copper

Show more

Finish

Coated

Smooth

Textured

Material

Steel

Length

Bespoke

Width

Bespoke

Height

Bespoke

Warranty description

50 year

Uniclass

Pr_25_71_51_15 Carbon steel sheetsPrimary

CAWS

H31/10 Metal

H31/120 Metal

Specification data - Carbon steel sheets

Standards

-

Flashings

Manufacturer's standard.

Guidance for specification option:

A range of matching flashings and ancillaries are available. Contact manufacturer for details.

Material

Pre-coated carbon steel.

Grade

PLX.

Dimensions

-

Length

-

Manufacturer guidance

Consult manufacturer for details and insert requirements.

Width

-

Manufacturer guidance

Consult manufacturer for details and insert requirements.

Sheet thickness

0.6 mm.

Finishes

-

Finish

Pro.

Guidance for specification option:

Smooth.

Pural.

Guidance for specification option:

Textured.

Colour

Acorn Brown RR827 / SS0434.

Anthracite Grey RR2H8 / SS0087.

Brick Red RR7F2 / SS0742.

Cottage Red RR29 / SS0758.

Leaf Green RR594 / SS0874.

Metallic Copper RR979 / SS0778.

Metallic Dark Silver RR41 / SS0044.

Metallic Gold RR042.

Metallic Silver RR40 / SS0045.

Metallic Sterling RR974 / SS6045.

Mountain Grey RR23 / SS0036.

Nordic Night Black RR33 / SS0015.

Quarry Grey RR287 / SS0244.

Silver Fir Green RR5J3 / SS0975.

Snow White RR19 / SS0001.

Special order.

Guidance for specification option:

Other colours are available subject to minimum order quantities; consult manufacturer for details.

Reaction to fire

-

External face

To EN 13501-1, A1.

Batten size

40 x 40 x 35 mm.

45 mm, round.

Batten centres

470 mm.

570 mm.

Coefficient of thermal expansion

0.012 mm/m·K.

Guidance for specification option:

GreenCoat PLX offers an approximately 50% lower expansion coefficient in contrast to all other metals. This property allows for longer profiles/ sections (consult technical literature for details) and prevents buckling and deformation for many decades.

Accessories

Not required.

Solar photovoltaic panel.

Guidance for specification option:

Available with Pro finish only.

Sustainability data

Contains Red List materials

No

Country of material origin

Sweden

Country of product manufacture

United Kingdom

Material

Steel

Manufacturing plant location

Embodied carbon

A1-A3 (production stage) as defined in BS EN 15804

2.63 kg CO₂ eq/kg

Recyclability

95%

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

20 %

Third party certifications

Third party certifications

EPD

EPD

Greencoat colour coated steel EPD

R EACTION TO FIRE - CLASSIFICATION REPORT EUI-22-000041

R EACTION TO FIRE - CLASSIFICATION REPORT EUI-22-000041

Greencoat PLX Pural BT - Fire Accreditation

R EACTION TO FIRE - CLASSIFICATION REPORT EUI-22-000041

R EACTION TO FIRE - CLASSIFICATION REPORT EUI-22-000041

Greencoat Pro BT Fire certifications

ISO 9001 Quality Management

ISO 9001 Quality Management

ISO 9001 Metal Solutions

ISO 14001 Environmental Management Systems

ISO 14001 Environmental Management Systems

SSAB-Europe-Management-system-certificate-14001-EN-2018-03

ISO 9001 Quality Management

ISO 9001 Quality Management

SSAB-Europe-Management-system-certificate-9001-EN-2018-03

IATF 169492016

IATF 169492016

SSAB IATF 169492016

Literature

SSAB - GreenCoat Installation Guide

SSAB - GreenCoat Installation Guide

SSAB - GreenCoat Colours

SSAB - GreenCoat Colours

SSAB - 2019 UK GreenCoat story

SSAB - 2019 UK GreenCoat story

SSAB EPD GreenCoat - color coated steel sheets and coils

SSAB EPD GreenCoat - color coated steel sheets and coils

SSAB - GreenCoat Inspection and maintenance

SSAB - GreenCoat Inspection and maintenance

SSAB - GreenCoat PLX Pro BT

SSAB - GreenCoat PLX Pro BT

SSAB - GreenCoat PLX Pural BT

SSAB - GreenCoat PLX Pural BT

SSAB - GreenCoat-European guarantee

SSAB - GreenCoat-European guarantee

SSAB-GreenCoat-EPD-Color-Coated-Steel-Sheets

SSAB-GreenCoat-EPD-Color-Coated-Steel-Sheets

SSAB - GreenCoat Pro BT

SSAB - GreenCoat Pro BT

SSAB - GreenCoat Pural BT

SSAB - GreenCoat Pural BT

SSAB Greencoat Pural BT, Pural BT Matt VTT-S-00613-18

SSAB Greencoat Pural BT, Pural BT Matt VTT-S-00613-18

SSAB PX29354-1 EN 13501-1  Emea AB

SSAB PX29354-1 EN 13501-1 Emea AB

Metal Solutions Snow Guard System

Metal Solutions Snow Guard System

Metal Solutions - ISO 9001 2015 Certificate

Metal Solutions - ISO 9001 2015 Certificate

Metal Solutions Rainwater System

Metal Solutions Rainwater System

Topclip Capping System

Topclip Capping System

Greencoat - Broof EN13501-5

Greencoat - Broof EN13501-5
