Application

For internal and external use to waterproof, separate and compensate for vapour pressure prior to laying of ceramic tile and natural stone coatings for domestic, commercial, industrial uses (such as industrial kitchens, food industries, warehouses) and for street furniture.

Description

Uncoupling and anti-cracking waterproof membrane with high adhesion for balconies, terraces and horizontal surfaces before the laying of ceramic tiles or natural stone. It creates a waterproof surface even when overlaid on substrates that are cracked, have not been perfectly cured or might contain vapour pressure due to residual substrate moisture content.

Features and benefits:

  • Waterproofs any surface, old or new, damp or dry, cracked or subject to dimensional variations.
  • Compensates for hygrometric shrinkage and thermal deformation stress.
  • Reduces on-site working times - waterproofing and laying of the coating without waiting, and withstands foot traffic immediately.
  • Solves the problem of respecting substrate joints in staggered or diagonal laying (cuts in doorways).

The membrane is a high-technology, multi-layer composite polymer system comprising:

  • PA - Hydrophobic PA fibres with high tensile strength to guarantee a superior and more evenly distributed available contact surface.
  • HDPE - Waterproof and variable geometry HDPE structure to guarantee physical separation between the substrate and the flooring.
  • TNT - Highly breathable sheet to guarantee passage of the vapour from uncured screeds or screeds with high residual humidity and to guarantee high levels of adhesion to the substrates.

Applications:

For internal and external use to waterproof, separate and compensate for vapour pressure prior to laying of ceramic tile and natural stone coatings for domestic, commercial, industrial uses (such as industrial kitchens, food industries, warehouses) and for street furniture.

– Suitable substrates:

  • Screeds, including any that are cracked and not completely cured or with possible vapour pressure caused by residual humidity.
  • Existing ceramic, marble floor tiles, natural stone floorings anchored to the substrate.
  • Cured concrete.
  • Fibre-cement and plaster-board panels anchored to the substrate.

General information
Material

Multi-layer composite polymer system comprising polyamide, high-density polyethylene (HDPE) and TNT

Uniclass 2015
Plastics sheets (Pr_25_57_65_60)Primary
Specification data - Plastics sheets
Product Reference

Green Pro

Standard product features

Material:

Multi-layer composite polymer system comprising polyamide, high-density polyethylene (HDPE) and TNT.

Colour:

White/ transparent/ green.

Thickness:

≈4 mm.

Roll size (w x l):

1.15 x 20 m.

Elongation (to DIN 53504 and ISO 254):

  • Longitudinal: 20%.
  • Transversal: 25%.

Technical properties (in combination with H40® Adhesive and porcelain tiles):

  • Resistance to strain parallel to the laying surface (to UNI 10827 and BS EN 120041): 1.8 N/mm².
  • Resistance to strain parallel to the laying surface, laying in water (to UNI 10827 and BS EN 120041): 1.8 N/mm².
  • Resistance to strain parallel to the laying surface, laying after heat (to UNI 10827 and BS EN 120041): 1.4 N/mm².
  • Resistance to strain parallel to the laying surface, laying in frost/ thaw (to UNI 10827 and BS EN 120041): 1.8 N/mm².
  • Compressive strength: 38 N/mm².
  • Resistance to dynamic stress: Robinson Test with porcelain tiles (10 mm thickness, to ASTM C 627): No breakage; classification: Extremely heavy and high impact loads in commercial and industrial buildings.
  • Impact noise damping (ΔLw, to BS EN ISO 717-2): 9 dB.
  • Thermal resistance (R-value, to BS EN 12664): 0.030 m²K/W.
