Description

Glass-reinforced concrete (GRC) cladding/ rainscreen cladding.

Features and benefits:

  • High strength.
  • A1 non-combustible fire performance.
  • Lightweight.
  • Environmentally friendly.

General information

Finish

Guidance for specification option:

Insert requirement.

Finish

Guidance for specification option:

Insert requirement.

Uniclass

Ss_25_20_33_35 Glass fibre-reinforced concrete (GRC) wall cladding systemsPrimary

CAWS

H40/110 GRC cladding

H92/120 Rainscreen cladding

Specification data - Glass fibre-reinforced concrete (GRC) wall cladding systems

Product Reference

GRC Cladding/ GRC Rainscreen Cladding

Panel size

Guidance for specification option:

Insert requirements; panels can be designed with variable geometry and size.

Joints

Guidance for specification option:

Insert requirements.

Finish

Guidance for specification option:

Insert requirement.

Colour

Guidance for specification option:

Insert requirement.

Standard product features

Technical characteristics (typical sprayed GRC):

  • Bending strength: 20 MPa.
  • Compressive strength: 50 MPa.
  • Impact strength: 10 kJ/m².
  • Dr density: 1950 kg/m³.
  • Frost resistance: T100.
  • Water absorption: 7%.
  • Fire resistance: Class A1.

Product Options

Finish:

Concrete elements are typically manufactured in moulds that are assembled either from wood or composite materials, such as steel or plastic. The interior part of the mould provides the finished shape and surface of the unit. The mould can be smooth in texture, or have a project-specifically designed composite inlay for imprinting. Additional finishing to the surface can be provided to the de-moulded unit, either by sandblasting, acid-etching or polishing. Typically, a hydrophobic coating is applied to the visible surfaces prior to packing. An anti-graffiti layer can also be applied, should a project require additional protection against vandalism.

Colour:

Concrete colour is dependent on the colour of the cement used. Typically, white or grey tonality is used where the designer is looking for a traditional concrete look. Modern facades call for more bespoke colour specification, which can be achieved by means of using either powdered pigments (added during production of concrete mix) or by applying a surface coating (premixed to the required colour). Concrete dyed in mass will manifest natural mottled tonality as a result of irregular cement hydroxylation in the concrete curing process. Surface-applied coatings tend to be more uniform in nature.

Fixing:

Depending on their size and geometry, concrete facade panels can be attached to the building structure by means of a range of standard aluminium or bespoke stainless steel framework.

Literature

GRC Facades - Concrete Cladding brochure for GRC/GFRC, UHPC, Precast

GRC Facades - Concrete Cladding brochure for GRC/GFRC, UHPC, Precast
