Grainger Autumn - Clay Bricks
Verified by manufacturer 3 days ago
Rolled facing brick. Manufactured to BS EN77-1.
Application
Brickwork applications, in accordance with BS EN 1996 and PD6697.
Description
Rolled facing brick. Manufactured to BS EN77-1.
Features and benefits:
- Red in colour.
- Manufactured in Throckley.
- Brick type: wirecut extruded.
- Vertically perforated.
- Guaranteed for 60 years in buildings or 20 years in boundary walls. Excludes paving, steps and ramps.
General information
Color | Red |
Finish | Rolled |
Material | Clay |
Shape | Rectangle |
Length | 215 mm |
Width | 102 mm |
Height | 65 mm |
Warranty description | 60 year 20 year Manufacturer guidanceGuaranteed for 60 years in buildings or 20 years in boundary walls. Excludes paving, steps and ramps. |
Uniclass | |
CAWS | F10/5 Facing brickwork F10/110 Clay facing brickwork |
Specification data - Clay bricks
Standard | To BS EN 771-1. |
Brick description | Facing brick. |
Work size (length x width x height) | 215 x 102 x 65 mm. |
Tolerances | |
Mean value | T2.Guidance for specification option: ±L4W3H2. |
Range | R1.Guidance for specification option: L9W6H5. |
Compressive strength | |
Mean compressive strength (minimum) | ≥60.0 N/mm². |
Category | I. |
Durability designation | F2 S2.Guidance for specification option: F2 - Severe exposure. |
Density | |
Gross dry | 1560 kg/m³. |
Net dry | 2220 kg/m³. |
Tolerance | D1. |
Water absorption | ≤10%. |
Configuration | Vertically perforated. |
Thermal conductivity | 1.13 W/m·K. |
Thermal resistance | 0.09 m²KW. |
Water vapour permeability | 5/10 µ. |
Bond strength | 0.15 N/mm². |
Reaction to fire | Class A1 to BS EN 13501-1. |
Weight | 192.0 kg/m². |
Sustainability data
Country of product manufacture | United Kingdom |
Material | Clay |
