Geberit Duofix element for bidet, 112 cm, universal: 50 x 10 cm - Pre-Plumbed Installation Frame
Verified by manufacturer 3 days ago
Geberit Duofix element for washbasins.
Application
- For metal and wood frame walls.
- For Geberit Duofix system walls.
- For installation in part- or room-height prewalls.
- For installation in room-height partition walls.
- For floor constructions 0–25 cm.
- For wall-hung bidets with deck-mounted tap.
Description
Geberit Duofix element for bidet, 112 cm, universal: 50 x 10 cm.
Features and benefits:
- Statically self-supporting frame, protected against corrosion with powder coating.
- With pull-out plate for lateral fastening above the element on metal or wood profiles or on Geberit Duofix system studs.
- Alternative fastening point for wall anchors.
- Rotating foot plates, suitable for installation in U profiles UW 50 and UW 75.
- Foot plates that can be mounted in Geberit Duofix system rail without tools, without additional components.
- Galvanized non-slip leg supports protected against corrosion.
- Fastening distance for wall-hung bidet 18 or 23 cm.
- Height-adjustable bidet fastening.
- Fastening for connection bend, height-adjustable and sound-absorbing.
- Tap attachments adjustable in width and height.
- Self-adhesive sealing washer, fleece-laminated.
- Protection plug for one-time pressure test with cold water up to a maximum of 15 bar / 1500 kPa.
Included in the kit:
- Two wall anchors.
- Two angle stop valves 1/2".
- Two elbow tap connectors Rp 1/2" / R 1/2", compatible with MF.
- Two sealing washers.
- Two sound insulation bases.
- Two insulating sleeves.
- Fastening and protection material.
General information
Color | Blue |
Finish | Galvanized |
Material | Steel |
Shape | Rectangle |
Length | 500 mm |
Width | 100 mm |
Height | 1120 mm |
Uniclass | |
CAWS | N13/66 Pre-plumbed frame system N13/500 Pre-plumbed frame system |
SKU Code | 111.545.00.2 |
Specification data - Pre-plumbed installation frames
Form | Support frames. |
Materials | Galvanized steel. |
Size | 100 x 500 x 1120 mm. |
Sustainability data
Material | Steel |
