GDS Door - Flush Double Glazed High Acoustic Door - Flushed double glazed, High Acoustic
Verified by manufacturer 2 months ago
ISO 9001 Quality Management
Certificate type
ISO 45001 Health and Safety Management
Certificate type
6 mm thick, double glazed toughened glass door.
Application
Open-plan commercial offices and workplace environments.
Description
The combination of an aesthetically stylish appearance with acoustic performance makes Apton GDS Doors a winning combination.
The GDS Double Glazed Acoustic Doors create a feeling of privacy whilst maintaining an unrestricted visual of an open office.
Features and benefits:
- Aesthetic stylish appearance.
- Acoustic performance.
- A wide choice of ironmongery.
- Supplied with either hinge or offset pivot.
- Ease of installation.
General information
Color | Clear Beige Black Blue Brown |
Finish | Anodized Satin Powder-coated |
Material | Glass Aluminium |
Shape | Rectangle |
Length | Bespoke |
Width | Bespoke |
Height | Bespoke |
Warranty description | Five year |
Uniclass | |
CAWS | L20/55 Doorsets L20/480 Doorsets |
Specification data - Aluminium doorsets
Configuration | Single leaf, single action.Guidance for specification option: Insert drawing reference number. |
Doorset size | Guidance for specification option: Available height up to 3000 mm; insert requirements or drawing reference number. |
Performance | |
Acoustic performance | Up to 41 dB (Rw).Guidance for specification option:
|
Strength and durability | To BS5234, BS6180 and BS6399.Guidance for specification option: Structural stability to BS5234, BS6180, BS6399. |
Frame | |
Material | 40 x 44 mm aluminium profiles. |
Door leaf | |
Thickness | 6 mm. |
Glazing | |
Type | Double glazed toughened/ laminated glass.Double glazed switch glass.Guidance for specification option: Consult manufacturer for details. |
Manifestation | Not required.Required.Guidance for specification option: Insert requirements; contact manufacturer for details on optional manifestations and graphics. |
Hardware | Polyester powder-coated aluminium.Guidance for specification option: Insert requirements; contact manufacturer for more details. Satin anodized aluminium.Anodized aluminium.Guidance for specification option: Inquire with manufacturer for special anodized finish options. |
Accessories | Not required.Blinds. |
Hardware | Hinge. Guidance for specification option: A wide range of hardware options are available. Insert requirements; consult with manufacturer for details. Offset pivot. |
Sustainability data
Contains Red List materials | No |
Country of material origin | United Kingdom |
Country of product manufacture | United Kingdom |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 90 % |
BIM objects
| Platform | Compatible | Version |
|---|---|---|
 Revit | - | 1 |
Third party certifications
ISO 9001 Quality Management
BS EN ISO 9001:2015
ISO 45001 Health and Safety Management
ISO 45001:2018 Occupational Health and Safety Management Systems
Literature
GDS Door -Flushed Double Glazed
