FloBoard - Drainage Membrane
Verified by manufacturer today
A range of drainage membranes: FloBoard CM8 and FloBoard CM20.
Application
Atal FloBoard CM8 is suitable for walls, above and below ground level, Type C waterproofing applications and damp-proofing applications.
Atal FloBoard CM20 is suitable for walls, floors, vaults, tunnels, and above- and below-ground level waterproofing applications.
Description
Atal FloBoard CM8 is an 8 mm studded membrane incorporating a tough HDPE mesh lathing welded to the front face, allowing the direct application of various plaster finishes, adhesive ‘dabs’ and plasterboards and delivering a Grade 3 environment to BS 8102:2009 and NHBC Chapter 5.4.
The FloBoard CM20 cavity drain membrane is a 20 mm studded membrane, suitable for Type C waterproofing and delivering a Grade 3 environment to BS 8102:2022 and NHBC chapter 5.4. CM20 is the highest drainage capacity membrane in the Atal waterproofing range.
Features and benefits:
- Part of a type C cavity drain membrane system in line with BS 8102:2022.
- Quick to install.
- Little or no damage to the existing structure.
- Low and high temperature tolerance.
- Creates a dry, habitable living space in areas previously suffering from damp/ wet conditions.
- Waterproof, salt-inhibiting, root and contaminant-resistant.
General information
Color | Clear Black |
Material | High density polyethylene (HDPE) |
Shape | Rectangle |
Length | 10000 mm 20000 mm |
Width | 2000 mm |
Height | 7 mm 20 mm |
Uniclass |
SKU Code | CM8, CM20 |
Sustainability data
Material | High density polyethylene (HDPE) |
Literature
Atal FloBoard 4E Datasheet
Atal FloBoard CM8 Datasheet
Atal FloBoard CM20 Datasheet
Atal CM Membrane Plugs Datasheet
