Fibo 850 100 mm 3.6 N Concrete Block

Name: Fibo 850 100 mm 3.6 N Concrete Block
Brand: Lignacite Ltd
SKU: rxJ1uYvXyPw3w91SqpBCmw

Verified by manufacturer 2 days ago

Lignacite Ltd

Product certifications:

EPD
Certificate type
ISO/IEC 27001:2022 Information security, cybersecurity and privacy protection — Information security management systems — Requirements
Certificate type
BSI Kitemark
Certificate type

Fibo 850 lightweight concrete blocks are suitable for general-purpose walling applications.

Jump to:

BOS

+44 (0)1842 810678 Website

Application

Fibo 850 is suitable for housing and building extension projects. They can also be used to construct walls in buildings where blockwork with a low self-weight has been specified (e.g., partition walls on floor slabs).

Typical locations include:

Inner and outer leaves of external cavity walls
Internal walls, including fire breaks
Below ground (7.3 N/mm² strength blocks should be used for walls exposed to the external ground).

Fibo 850 blocks have an open textured surface, which is ideal for applying plaster and render. Consult manufacturer for further finish recommendations.

For use in separating walls meeting the requirements of Part E of the Building Regulations, we recommend the use of products from the Lignacite GP and Ligancrete ranges.

Description

Fibo 850 super lightweight concrete blocks are suitable for general-purpose walling applications. They provide a good base for plasters, renders and fixings, and the 100 mm option combines easy handling with great thermal efficiency values.

They are also Category 1 masonry units manufactured under a BSI-certified Quality Management System, which is BS EN 9001 compliant.

Manufactured to BS EN 771-3, they consist of expanded clay aggregates and a mixture of other naturally occurring raw materials and cement. The clay aggregate is produced from carefully selected clays, which are bloated through heat expansion to create a low density, porous aggregate with numerous cavities. This makes Fibo 850 incredibly light and thermally efficient.

Features and benefits:

Provides a high level of thermal insulation, reducing the amount of additional insulation required after installation.
Lightweight, easy to handle, and quick to lay.
Loadbearing.
Provides a high level of fire protection (Class A1).
For use internally and externally, above and below ground.
Provides a strong background for direct application of plasters and renders (no bonding agents required).
Fixings will be held securely by the block (and can be nailed in directly).
Certification to BES 6001 V4.0 will allow credits to be gained under environmental assessment schemes such as BREEAM.
BSI Kitemarked to BS EN 771-3.

General information

Color	Grey
Finish	Textured
Material	Concrete Guidance for specification option: (expanded clay aggregates and other naturally occurring raw materials and cement).
Shape	Rectangle
Length	440 mm
Width	100 mm
Height	215 mm

Uniclass	Pr_20_93_52_01 Aggregate concrete blocksPrimary
CAWS	E60/297 Proprietary infill blocks F10/18 Concrete facing blockwork F10/355 Concrete common blockwork

SKU Code	F1003

Product range	Fibo Super-Lightweight Block Range

Specification data - Aggregate concrete blocks

Classification data
Standard	To BS EN 771-3.
Block description	Fine textured, loadbearing units for facing and general purpose applications.
Appearance	Medium grey in colour with a fine textured surface.
Configuration	Group 1.
Compressive strength	-
Mean value	3.6 N/mm².
Category	1.
Thermal conductivity	0.27 W/m·K at 3% moisture content (internal use).
Thermal resistance	0.37 m²K/W at 3% moisture content; 0.35 m²K/W at 5% moisture content.
Work sizes (length x width x height)	440 x 100 x 215 mm.
Tolerance category	D1.
Density	-
Net dry density	850 kg/m³.
Reaction to fire	Class A1.
Moisture movement	0.6 mm/m.
Weighted sound reduction index, Rw	40–42 dB (dependent on application). Guidance for specification option: Plaster finish: 40 dB; plasterboard on dabs: 42 dB.
Fire resistance	Non-loadbearing wall (criteria E1): 3 hours; loadbearing wall (criteria RE1): 2 hours. Guidance for specification option: 100 mm width.
Third-party certification	BSI Kitemark approved.
Unit weight	8.5 kg. Guidance for specification option: Laid weight including mortar: 96 kg/m².

Sustainability data

Contains Red List materials	No
Country of material origin	United Kingdom
Country of product manufacture	United Kingdom
Material	Concrete Guidance for specification option: (expanded clay aggregates and other naturally occurring raw materials and cement).
Carbon dioxide equivalent
Carbon dioxide equivalent, as defined in BS EN 15804 Certified
Stage Normalised unit (kg CO₂ eq/kg) Declared unit (kg CO₂ eq/m²) Stage:A1–A3 ('Production stage') Normalised unit : 0.468 (kg CO₂ eq/kg) Declared unit : 39.8 Value guidance: A1-A3 Rounded down to two decimal places; manufacturer's value is 0.443 kg·CO2e/kg. This figure is derived from the carbon value as per the EPD (35.5 kgCO2e) divided by the unit mass (80 kg/m²).
Recyclability	100%
Recycled content As defined in clause 7.8 of BS EN ISO 14021	0 %
Expected Life	100 year Guidance for specification option: When properly constructed, the durability of walls built using Fibo 850 products will match that of traditional masonry and will fulfil their intended function for the life of the building in which they have been installed (typically 100 years). The blocks themselves will require no maintenance. Maintenance for walls will normally include the replacement of sealant in movement joints and at junctions / openings. Repointing for walls that are exposed to the elements may be necessary towards the end of their service life.
