FCFcl Cavity Clad - Cavity Barrier - Cavity Barrier
Verified by manufacturer 8 days ago
FCFfl 75 (1200 x 600 x 75 mm)
FCFfl 75 (1200 x 600 x 75 mm)
Designed to protect the building void between the inner and outer construction elements.
Application
- Horizontal and vertical cavities between the inner and outer construction elements of rainscreens.
- Ceiling cavity barriers.
- Under floor cavity barriers.
- Slab edge barriers.
Building materials:
- Concrete slabs, columns and walls.
- Curtain wall assemblies.
Description
Designed to protect the building void between the inner and outer construction elements.
Comprises of a one-piece closed-dimension stone wool core.
The product is encased with an aluminum foil face which provides class '0' rating and exhibits excellent resistance to smoke.
Features and benefits:
- Provides a resilient lateral compression which is required to ensure a tight fit.
- Tested to EN 1366-4 and BS 476.
- Classification to EN 13501-2 and EN 13501-1.
- Air permeability to EN 1026 to 600 Pa.
- Acoustic isolation to EN 10140 to 31 dB.
- Low compression rate for easy installation.
- Superior level of sustainability.
- Encased fibre migration for air plenum use.
- Floor and wall voids up to 450 mm wide.
General information
Color | Silver Yellow |
Finish | Foil |
Material | Stone wool |
Shape | Rectangle |
Length | 1200 mm |
Width | 1000 mm 1200 mm |
Height | 75 mm 100 mm 120 mm |
Uniclass | |
CAWS | P10/420 Sleeved mineral wool small cavity barriers P10/435 Ventilated cavity barriers P10/70 Sleeved small cavity barriers P10/77 Ventilated cavity barriers |
SKU Code | 546210, 053046, 568148, 546209 |
Specification data - Mineral wool fire-stopping
Material | |
Third-party certification | European Technical Assessment ETA-21/1062. UL-EU certificate UL-EU-01248-CPR. CE marking 2531-CPR-CXO10328. |
Type | Structural stone wool composite. Guidance for specification option: Yellow. |
Density | 80 kg/m³. |
Facing | Foil. Guidance for specification option: Silver. |
Fire performance | Fire resistance to EN 1366-4, up to 120 minutes. |
Sound insulation rating | Acoustic performance to EN 10140, 31 dB. |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | Manufacturer's standard. Guidance for specification option: Consult manufacturer for details. |
Accessories | None. Aluminium foil tape. Guidance for specification option: 558505. 45 m roll of 100 mm-wide aluminium foil tape. |
Technical characteristics, other | Compression: 5 or 10 mm. |
Attachment | Multi Purpose Bracket 230. Guidance for specification option: 563201. A2 stainless steel fixing bracket, 230 x 25 x 1 mm. Multi Purpose Bracket 390. Guidance for specification option: 551868. A2 stainless steel fixing bracket, 390 x 25 x 1 mm. Multi Purpose Bracket 500. Guidance for specification option: 551954. A2 stainless steel fixing bracket, 500 x 25 x 1 mm. Multi Purpose Bracket 600. Guidance for specification option: 570346. A2 stainless steel fixing bracket, 600 x 25 x 1.5 mm. Other. Guidance for specification option: Insert requirements.
Manufacturer guidanceFixing points: 300 mm. |
Thickness | 75 mm. Guidance for specification option: 546210. |
Air permeability | To EN 1026, 600 Pa |
Thermal Conductivity: | 0.35 bis 0.36 W/m·K. |
Sustainability data
Material | Stone wool |
