Eclipse
Description

Eclipse is available in a wide variety of shades from blacks to creams. This high quality porcelain stoneware gives designers the ability to create amazing projects. Certain tiles (Carmal, Marenga, Susanah and Winder) incorporate up to 40% recycled material.

General information
Finish

Brushed

Natural R10

Slate R11 (A+B+C)

Uniclass 2015
Pr_35_93_96_19 Ceramic tilesPrimary
CAWS

M40/110 Tiling to

M40/5 Tiling to

Specification data - Ceramic tiles
Product Reference

Eclipse

Size (w x h)

150 x 1200 mm

300 x 600 mm

300 x 1200 mm

600 x 600 mm

600 x 1200 mm

Colour

Annie 2GHP510

Bethan 2GHP509

Bosanova 2GHP517

Carmal 2GHP512

Ciara 2GHP507

Connection 2GHP516

Gillian 2GHP508

Jestico 2GHP520

Mandy 2GHP511

Marenga 2GHP515

Sile 2GHP519

Soufle 2GHP514

Susanah 2GHP513

Swing 2GHP518

Trident 2GHP506

Winder 2GHP505

Finish

Brushed

Natural R10

Slate R11 (A+B+C)

Accessories

Not required

One piece step tread, 340 x 600 mm

One piece step tread, 340 x 1200 mm

Round top plinth

Square top plinth

Step tread

Standard product features

Tile depth:

10 mm.

Dimensions and surface quality:

Conforms to ISO 10545-2.

Water absorption:

ISO 10545-3: < 0.05%.

Flexural strength:

ISO 10545-4: 42 N/mm².

Deep abrasion resistance:

ISO 10545-6: 140 mm³.

Linear thermal expansion:

ISO 10545-8: 7 MK-1.

Thermal shock resistance:

Conforms to ISO 10545-9.

Frost resistance:

Conforms to ISO 10545-12.

Chemical resistance:

Conforms to ISO 10545-13.

Stain resistance:

ISO 10545-14: Class 5.

Slip resistance:

DIN 51130 - 51097.
