Cromwell Walling
Description

A range of hydraulically pressed, homogeneous, reconstructed stone walling available in three finishes:

– Pitched Face:

The method of splitting and dressing ensures each stone is different.

– Rustic:

Rustic Walling is a rounded, softened, and less defined finish produced by a tumbling, giving the appearance often seen in reclaimed natural stone walling where weathering and the process of reclaiming and redressing have taken away the sharper appearance of newer stones.

– Split Face:

Similar to Pitched Face walling, this product has a less prominent, flatter textured face, which is well suited to commercial and high quality housing where this feature is preferred. Available in Yorkstone to replicate natural stone walling.

For each finish, stones are supplied in packs of single sizes to allow the design and construction to meet individual requirements.

Values and details of properties determined under BS EN 771-5, e.g. compressive strength, are available from Marshalls.

General information

Uniclass 2015

Pr_20_93_52_50 Manufactured stone blocksPrimary

CAWS

F10/25 Manufactured stone blockwork

F10/295 Manufactured stone blockwork

Specification data - Manufactured stone blocks

Product Reference

Cromwell Walling

Type

Pitched Face

Split Face

Rustic

Colour

Weathered

Pitched Face, Rustic.

Yorkstone

Pitched Face, Rustic, Split Face.

Stone face sizes (course height x length)

65 mm x 220 mm

Pitched Face, Rustic, Split Face.

140 mm x 180 mm

Rustic only.

140 mm x 220 mm

Rustic only.

140 mm x 260 mm

Rustic only.

140 mm x 300 mm

Pitched Face, Rustic, Split Face.

140 mm x 365 mm

Pitched Face, Rustic, Split Face.

140 mm x 440 mm

Pitched Face, Rustic, Split Face.

As shown on drawing ___

Quoins

Dressed on site from standard stones to match adjacent walling

Use standard stones supplied with one faced end

available only in Rustic face, sizes 65 x 220 mm, 140 x 220 mm, 140 x 180 mm and 140 x 260 mm.

Specials to match adjacent walling

Squints

Not required

External angle ___° specials to match and course with adjacent walling

Internal angle ___° specials to match and course with adjacent walling

As shown on drawing ___

Standard product features

Course heights:

65 mm and 140 mm are available for all types.

Bed size (nominal):

100 mm.

Product Options

Quoins:

Available to order in any standard course height. Hand dressing on site achieves the same effect.

Squints:

Available to order in any standard course height, to any required angle using cut and bond technology.
