Creation 30 - LVT - Flooring

Verified by manufacturer 3 months ago

Gerflor Flooring UK Limited

Synthetic, decorative, flexible, anti-static, abrasion group T floor coverings available in tile or plank form with a 0.30 mm transparent wear layer.

Jump to:
BOS
01625 428 922 Website

Application

Suitable for residential and light commercial applications.

Description

Creation 30 is a decorative range of glue-down luxury vinyl tiles (LVT) and planks. It comprises a 0.30 mm transparent wear layer, a high definition design film and a resilient comfort core to provide noise absorption and comfort underfoot. Finished with realistic embossing and micro-bevelled edges, the range comes with an enhanced surface treatment, Protecshield™ for improved scratch and stain resistance, easy cleaning and an ultra matt finish. Available in 44 wood and 16 mineral design references across four size formats, offering optimum design choice.


Features and benefits:

  • Protecshield™ surface treatment for easy cleaning and maintenance.
  • Slip resistant - R10.
  • Wear Group T/ Type Binder classification I.
  • Easy to install.
  • Realistic embossing and micro-bevelled edges for enhanced authenticity.
  • Wide range of designs – 60 references across a range of size formats.
  • 35 references are also available as a Solid Clic installation version (specified separately).
  • 100% recyclable and contains up to 35% recycled content.
  • High level of indoor air quality: total volatile organic compounds (TVOC) after 28 days: <10 µg/m³.
  • Can be installed with auto adhesive acoustic underlayer Smartfix 16 dB : for enhanced sound insulation (specified separately).
  • Matching skirtings and coverstrips available (specified separately).


Installation and maintenance:

Should be installed in accordance with the BS 8203: 2017 Code of practice for installation of resilient floor coverings.

Installation and maintenance instructions are available.

General information

Color

Other

Guidance for specification option:

Please consult manufacturer for options.

Finish

Matt

Material

Vinyl

Shape

Rectangle

Square

Length

184 mm

230 mm

457 mm

610 mm

Width

1219 mm

1500 mm

914 mm

610 mm

Height

2 mm

Warranty description

12 year

Uniclass

Pr_35_57_71_68 Polyvinyl chloride (PVC) tilesPrimary

CAWS

M50/10 Resilient floor tiling

M50/110 Resilient floor tiling

Product range

Tiles / Luxury Vinyl Tile (Flooring)

Specification data - Polyvinyl chloride (PVC) tiles

Standard

To BS EN ISO 10582.

Use class

To BS EN ISO 10874, class 23–31.

Guidance for specification option:

Residential- Light commercial use.

Slip potential

-

Slip resistance value (SRV) (minimum)/ Pendulum test value (PTV) (minimum)

R10.

Guidance for specification option:

To DIN 51130, slip resistance wet.

Recycled content

35%.

Guidance for specification option:

Contains up to 35% recycled content.

Size

184 x 1219 mm.

Guidance for specification option:

Number of planks/ tiles and sqm per box: 15/ 3.36 m².

184 x 1219 mm. (Chevron)

Guidance for specification option:

Number of planks/ tiles and sqm per box: 14/ 3.14 m².

230 x 1500 mm.

Guidance for specification option:

Number of planks/ tiles and sqm per box: 11/ 3.80 m².

457 x 914 mm.

Guidance for specification option:

Number of planks/ tiles and sqm per box: 9/ 3.76 m².

610 x 610 mm.

Guidance for specification option:

Number of planks/ tiles and sqm per box: 9/ 3.35 m².

Thickness

2.0 mm.

Guidance for specification option:

To EN ISO 24346.

Colour and pattern

Please consult manufacturer's brochure for options.

Wear layer

0.30 mm.

Guidance for specification option:

Thickness of wear layer.

Weight

3460 g/m².

Guidance for specification option:

To EN ISO 23997.

Static electricity

<2 kV.

Guidance for specification option:

Static Electrical Propensity To EN 1815.

Fire rating

Bfl-s1.

Guidance for specification option:

To BS EN 13501-1.

ThermalConductivity

0.25 W/m·K.

Guidance for specification option:

To BS EN 12524.

Surface treatment

Protecshield™

VOC emissions

<10 µg/m³.

Guidance for specification option:

To ISO 16000-6, TVOC after 28 days.

Wear group

T.

Binder

Type I.

Guidance for specification option:

Binder content to BS EN ISO 10582.

Accessories

Matching skirtings.

Paintable white skirtings.

Matching coverstrips.

Entrance matting.

Underlay.

Show more

Manufacturer guidance

Consult manufacturer and insert requirements.

Dimensional stability (to BS EN ISO 23999)

≤ 0.25 %.

Guidance for specification option:

Average measured value, ≤ 0.10 %.

Residual indentation (to EN-ISO 24343-1)

≤ 0.10 mm.

Sustainability data

Contains Red List materials

No

Country of product manufacture

Europe

Recyclability

100%

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

35 %

Guidance for specification option:

Contains up to 35% recycled content.

BIM objects

BOS

NBS BIM Object Standard

This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.

Find out more about the NBS BIM Object Standard.

Platform Compatible Version
IFC
-

1

Revit
-

1

Literature

Creation 30 - 2022 Collection - Card

Creation 30 - 2022 Collection - Card

Finishing Solutions for LVT Flooring

Finishing Solutions for LVT Flooring
