Application

Suitable for:

  • Floors.
  • Floating floors (consult manufacturer for underlay options).
  • Use with underfloor heating
  • Secret nail (manufacturer recommends Ted Todd bitumen backed paper for moisture barrier; not suitable for Amberley, Haldon or Stonor).
  • Structural floors/ joists (maximum 400 mm centres; not suitable for Amberley, Haldon or Stonor).

Description

Engineered wood flooring, designed to be laid in a plank format.

Features and benefits:

  • Part of the CRAFTED TEXTURES collection; consult manufacturer's literature for other formats.
  • EU Timber Regulation (EUTR) compliant.
  • FSC Mix Credit.
  • Can be fully bonded to subfloor (with Ted Todd MS Flex high strength adhesive).

Applications:

Suitable for:

  • Floors.
  • Floating floors (consult manufacturer for underlay options).
  • Use with underfloor heating
  • Secret nail (manufacturer recommends Ted Todd bitumen backed paper for moisture barrier; not suitable for Amberley, Haldon or Stonor).
  • Structural floors/ joists (maximum 400 mm centres; not suitable for Amberley, Haldon or Stonor).

Can be installed over:

  • Concrete (dry, flat).
  • Plywood.
  • Screed (dry, flat; manufacturer recommends Primerfast moisture barrier).

Related products:

A range of complementary products is available, including formed treads and risers, L-sections, T-sections, reducers, scotia, skirting and architraves. Consult manufacturer for details.

Guarantee:

  • 15 mm-thick planks: 20-year product warranty.
  • 20 mm-thick planks: 25-year product warranty.

Certification:

Certification:20 mm-thick planks: FSC 100%.

General information
Uniclass 2015
Wood laminate strips and boards (Pr_25_71_97_93)Primary
Specification data - Wood laminate strips and boards
Product Reference

CRAFTED TEXTURES Collection - Plank

Type

Amberley

Suitable for floors and walls.

Arden

Suitable for floors only

Carrick

Suitable for floors only.

Coombe

Suitable for floors only.

Haldon

Suitable for floors and walls.

Holton

Suitable for floors only

Odell

Suitable for floors only.

Salcey

Suitable for floors only.

Stonor

Suitable for floors and walls.

Waresley

Suitable for floors only.

Wiston

Suitable for floors only.

Standard product features

Technical characteristics:

  • Grade: Nature.
  • Construction: Two ply engineered, 100% hardwood.
  • Edge detail: Micro bevelled.
  • Profile: Tongue and grooved to all sides.
  • Tolerance: ±0.50 mm/ 95% in tolerance.
  • Moisture content: 8–12% fair and average.
  • Fire rating to EN 13501-1 (flooring): D fl - s1.
  • Emissions to EN 14342: E1.
  • Humidity requirements: Between 40% and 60% relative humidity.
  • Janka hardness rating: 1120 lbf (4980 N).
  • Formaldehyde emission: E1.
  • Tonal variation: Medium natural.
  • Batch variation: Not advised to mix batches in one floor area.

Product Options

Size:

- Length:

Random, up to 2.2 m

- Width:

  • 15 mm-thick planks: 140 mm.
  • 20 mm-thick planks: 220 mm.

Wear layer:

  • 15 mm-thick planks: 4 mm hardwood (nominal).
  • 20 mm-thick planks: 6 mm hardwood (nominal).

Type:

- Amberley:

  • Thickness: 15 mm.
  • Wood species: European oak.
  • Finish: Naked skin lacquer.
  • Surface texture: Skip sawn.
  • Slip rating: Dry: Low risk; Wet: Moderate risk.
  • Tone: Grey.

- Arden:

  • Thickness: 20 mm.
  • Wood species: European oak.
  • Finish: Matt hardwax oil.
  • Surface texture: Coastal weathered.
  • Slip rating: Dry: Low risk; Wet: Moderate risk.
  • Tone: Neutral.

- Carrick:

  • Thickness: 20 mm.
  • Wood species: European oak.
  • Finish: Matt hardwax oil.
  • Surface texture: Shadow sawn.
  • Slip rating: Dry: Low risk; Wet: Low risk.
  • Tone: Mid.

- Coombe:

  • Thickness: 20 mm.
  • Wood species: European oak.
  • Finish: Matt hardwax oil.
  • Surface texture: Shadow sawn.
  • Slip rating: Dry: Low risk; Wet: Moderate risk.
  • Tone: Neutral.

- Haldon:

  • Thickness: 15 mm.
  • Wood species: American black walnut.
  • Finish: Burnished restoration oil.
  • Surface texture: Coastal weathered.
  • Slip rating: Dry: Low risk; Wet: Moderate risk.
  • Tone: Dark.

- Holton:

  • Thickness: 20 mm.
  • Wood species: European oak.
  • Finish: Matt hardwax oil.
  • Surface texture: Shadow sawn.
  • Slip rating: Dry: Low risk; Wet: Moderate risk.
  • Tone: Mid.

- Odell:

  • Thickness: 20 mm.
  • Wood species: European oak.
  • Finish: Matt hardwax oil.
  • Surface texture: Coastal weathered.
  • Slip rating: Dry: Low risk; Wet: Moderate risk.
  • Tone: Neutral.

- Salcey

  • Thickness: 20 mm.
  • Wood species: European oak.
  • Finish: Matt hardwax oil.
  • Surface texture: Coastal weathered.
  • Slip rating: Dry: Low risk; Wet: Moderate risk.
  • Tone: Dark.

- Stonor:

  • Thickness: 15 mm.
  • Wood species: European oak.
  • Finish: Naked skin lacquer.
  • Surface texture: Skip sawn.
  • Slip rating: Dry: Low risk; Wet: Moderate risk.
  • Tone: Dark.

- Waresley:

  • Thickness: 20 mm.
  • Wood species: European oak.
  • Finish: Matt hardwax oil.
  • Surface texture: Coastal weathered.
  • Slip rating: Dry: Low risk; Wet: Moderate risk.
  • Tone: Mid.

- Wiston:

  • Thickness: 20 mm.
  • Wood species: European oak.
  • Finish: Matt hardwax oil.
  • Surface texture: Shadow sawn.
  • Slip rating: Dry: Low risk; Wet: Moderate risk.
  • Tone: Dark.
