Corium Brick Cladding

Description

Corium Brick cladding systems are designed for use as a decorative and protective façade over external walls of buildings. The system consists of an extruded clay brick fixed to a coated steel tray. Corium is available in a wide range of colours and textures.

Features:

  • Corium bricks fired at temperatures between 1200–1600ºC, creating a consistent quality plate of optimum accuracy in thickness, profile and flatness.
  • The bricks are wiredrag, matt, flashed or plain to provide an authentic, lightweight replication of real brick.
  • Junctions between the bricks are pointed with a formulated mix.

General information

Features

Corium bricks fired at temperatures between 1200–1600ºC, creating a consistent quality plate of optimum accuracy in thickness, profile and flatness

The bricks are wiredrag, matt, flashed or plain to provide an authentic, lightweight replication of real brick

Junctions between the bricks are pointed with a formulated mix

Uniclass 2015

Ss_25_20_70_25 Drained and back-ventilated rainscreen cladding systemsPrimary

CAWS

H92/120 Rainscreen cladding

Specification data - Drained and back-ventilated rainscreen cladding systems

Product Reference

Corium Brick Façades

Bricks

As standard

65 x 215 mm

Colour

Available in a very wide range – consult manufacturer.

Texture and relief

Available in a very wide range – consult manufacturer.

Standard product features

Type:

Rainscreen.

Framing system:

  • A system of vertical aluminium carrier for the selected tiles.
  • Tiles are fixed to the horizontal carrier rails with concealed fasteners.
  • The carrier rails are suitable for use on a variety of sub-structures including blockwork, timber, concrete and steel.
  • Dependent on the individual requirements of the project, insulation can be fitted within the cavity between the substructure and the rear face of the tile. Projection of the support system is dictated by the thickness of the insulation and the requirement for a minimum unimpeded cavity of 20 mm.
  • The support systems are designed to withstand stresses and loads imposed by wind, structural deflections and seismic movements, and will be tested to meet all criteria and building codes.

Extruded Brick:

- Face size:

  • 215 x 65 mm as standard.
  • 217 x 315 special.

- Thickness:

22 mm.

Literature

Third party certifications

  • BRE Wimlas: 082/01 : Anchor support
