CMSDA SoundDeck Extra 35mm - Resilient Structural Acoustic Flooring
Verified by manufacturer 2 months ago
ISO 45001 Health and Safety Management
Certificate type
ISO 9001 Quality Management
Certificate type
Resilient structural acoustic flooring system.
Application
Specifically designed for refurbishment of timber floors and particularly suitable for precast and beam and block floors.
Applications include:
- Refurbishments.
- Residential apartments.
- New build.
- Commercial offices.
Description
SoundDeck Extra 35 mm is a resilient structural acoustic flooring system which can be directly installed to timber joists. This enhances the acoustic performance of the system, reducing the potential for resonance and squeaking problems once the floor is in use. It is constructed from P5 tongue and grooved chipboard with a layer of 10 mm acoustic foam resilient layer, and a layer of acoustic barrier.
Features and benefits:
- Enhances acoustic performance.
- Minimises construction height.
- Good low frequency sound insulation enhancement.
- Cost effective solution for timber constructions.
- Moisture-resistant and load-bearing chipboard (P5).
- For additional performance and levelling of newly installed timber joists, 6 mm Regupol® Isolating Strips may be used.
- Compliant to Approved Document E England and Wales for new build and refurbishment.
General information
Color | Brown Other |
Finish | Other |
Material | Chipboard Foam |
Shape | Rectangle |
Length | 2400 mm |
Width | 600 mm |
Height | 35 mm |
Uniclass | |
CAWS | K11/27 Acoustic separating floor system K11/275 Acoustic separating floor system K11/295 Floating floor system |
Specification data - Timber-lined composite sound-insulating boards
Sound insulation rating | To BS EN ISO 140-6, 17 dB ΔLw. |
Thickness | 35 mm.Guidance for specification option:
|
Dimensions | 2400 x 600 mm. |
Weight | 20 kg/m². |
Grade | P5 tongue and grooved chipboard. |
Resilient layer | 10 mm acoustic foam. |
Integral accessories | CMS Danskin Acoustics Flanking Band. |
Accessories | Not required. 6 mm Regupol® Isolating Strips. |
Sustainability data
Country of product manufacture | United Kingdom |
Material | Chipboard Foam |
Third party certifications
ISO 45001 Health and Safety Management
ISO 45001:2018
ISO 9001 Quality Management
SIG ISO 9001
