Ceramapanel Secret Fix

Name: Ceramapanel Secret Fix
Brand: jxXr1mWhhpHh3A22NpwFRT
SKU: 3pNM4bQEb1vtzRfnf5ULAY

Fairview Europe Ltd T/A Valcan

Secret fixed fibre cement concrete cladding panels.

Jump to:

+44 (0) 1278 428 245 www.valcan.co.uk

Application

Particularly suited to both internal and external modern commercial, residential and industrial buildings, where a natural facade is needed.

Description

A through coloured, compressed fibre cement facade panel available in 10 mm or 12 mm thicknesses, in A2-s1, d0 or A1 rating as required. It is both an aesthetically appealing and cost-effective cladding solution offering a natural appearance. It also has good acoustic dampening properties.

Features and benefits:

Achieves A1 (non-combustible) or A2 (limited combustible) rating to BS EN 13501-1

Cost effective.

Impact resistant.

Proven performance in harsh environments.

Short lead times and fast installation timeframes.

Panels supplied pre-squared.

Long lasting.

Low maintenance.

Can be finished off-site for easy and efficient installation.

High strength and environmental durability.

Through coloured.

Sound dampening benefits.

Graffiti resistant when coated with acrylic treatment (natural+ range).

Wide range of colours and finishes available.

Ten-year warranty.

Application:

Particularly suited to both internal and external modern commercial, residential and industrial buildings, where a natural facade is needed.

General information

Finish	Natural Contour Groove 2 mm deep grooves which can be adjusted according to design intent, not available with 8 mm. Natural Contour Lines, Raw Lines are spaced further apart to give the appearance of planks, smooth sanded finish, not available with 8 mm. Natural Contour Lines, Touch Lines are spaced further apart to give the appearance of planks, ribboned effect finish, not available with 8 mm. Natural Textures Raw Smooth sanded finish ideal for clean, modern facade finishes. Natural Textures Sandblasted Finely textured, mottled finish for a classic slightly weathered finish. Natural Textures Shot-Sawn Smooth but pitted surface giving depth and texture to the facade surface. Natural Textures Touch Ribboned effect giving the panels a subtle grooved finish. Natural+ Textures Raw Smooth finish with an anti-graffiti coating ideal for clean, modern facade. Painted Can be finished in any RAL or Pantone colour. Printed Insert requirements. Show more
Material	Fibre cement concrete
Uniclass 2015	Pr_25_71_52_25 Fibre-reinforced cement boardsPrimary
CAWS	H92/120 Rainscreen cladding

Specification data - Fibre-reinforced cement boards

Product Reference	Ceramapanel Secret Fix
Thickness	10 mm 18 kg/m². 12 mm 21.6 kg/m².
Panel size (l x w)	2500 x 1250 mm 3050 x 1250 mm
Fire rating (to BS EN 13501)	A1 A2-s1, d0
Finish	Natural Contour Groove 2 mm deep grooves which can be adjusted according to design intent, not available with 8 mm. Natural Contour Lines, Raw Lines are spaced further apart to give the appearance of planks, smooth sanded finish, not available with 8 mm. Natural Contour Lines, Touch Lines are spaced further apart to give the appearance of planks, ribboned effect finish, not available with 8 mm. Natural Textures Raw Smooth sanded finish ideal for clean, modern facade finishes. Natural Textures Sandblasted Finely textured, mottled finish for a classic slightly weathered finish. Natural Textures Shot-Sawn Smooth but pitted surface giving depth and texture to the facade surface. Natural Textures Touch Ribboned effect giving the panels a subtle grooved finish. Natural+ Textures Raw Smooth finish with an anti-graffiti coating ideal for clean, modern facade. Painted Can be finished in any RAL or Pantone colour. Printed Insert requirements.
Colour	Natural 13 colours available, consult manufacturer's literature and insert requirements. Natural + 13 colours available, consult manufacturer's literature and insert requirements.

Standard product features

Material:

Fibre cement concrete.

Fixing:

Secret fixed to aluminium carrier system. Keil, Fischer, and SFS fixings can be used to secret fix 10 mm or 12 mm panels to the aluminium carrier system. A minimum of 50 mm should be left from the edge of the panel for fixings.

Technical characteristics:

Density: 1600 kg/m³ (±50).

Modulus of elasticity (dry): Longitudinal: 14 GPa; transversal: 12 GPa.

Modulus of elasticity (wet): Longitudinal: 11 GPa; transversal: 9 GPa.

Bending strength (wet, untreated): ≥18 MPa.

Bending strength (wet, hydrophobic treated sheet, acrylic coated): ≥24 MPa.

Bending strength (dry): Longitudinal: 32 MPa; transversal: 22 MPa.

Compressive strength: 40 MPa.

Maximum water absorption (untreated): 25±2%.

Maximum water absorption (hydrophobic treated sheet): 9±3%.

Maximum water absorption (acrylic coated sheet, acrylic coated): 3±2%.

Vapour resistance factor (to EN 12572: 2016): 320 µ.

Thermal conductivity (to EN 12664: 2002): 0.42 W/mK.

Durability classification (to EN 12467: 2016): Category A.

Strength classification (to EN 12467: 2016, untreated sheets): Class 4.

Strength classification (to EN 12467: 2016, treated sheets): Class 5.

Durability:

The cement panel is highly durable and includes immunity to permanent water damage in both short and long-term exposure. It will not rot, burn or corrode and is unaffected by termites, air, steam, salt and sunlight. It is not adversely affected over a temperature range of -20 to +60°C.

Product Options

Colour:

Ceramapanel is available in two main colour ranges; the Natural range and the Natural+ range. The Natural + range is a coated finish and gives the colour a deeper, richer tone. This is an alkali- resistant varnish using a UV polymerizing system to make the sheets resistant to graffiti. This allows the panels to be cleaned more easily and maintained for many years. Meanwhile, the Natural range resembles nature’s earth tones and has a much more natural look.
