Cayenne - Clay Facing Brick
QA Certificate
Certificate type
A facing brick with red and white shades, and a sanded-coated and grained structure.
Description
The raw materials are excavated in Weichsel loam layers, the local loam of Aeolian origin dating from the Ice Age. This löss mainly consists of a silt-like fraction, suited ideally for the manufacturing of hand form bricks. By using specific sand types for surface covering, the desired colour is achieved.
Features and benefits:
- Hand formed.
- Multi-shade.
- Five joint styles available.
- Red base colour with white variations.
General information
Color | Red |
Material | Clay |
Shape | Rectangle |
Length | 215 mm |
Width | 102 mm |
Height | 65 mm |
Uniclass | |
CAWS | F10/5 Facing brickwork F10/110 Clay facing brickwork |
Specification data - Clay bricks
Standard | To BS EN 771-1. |
Brick description | Facing brick. |
Appearance | Red and white shades, and a sanded-coated and grained structure. |
Work size (length x width x height) | 214 x 101 x 65 mm. |
Tolerances | - |
Mean value | T2. |
Range | R1. |
Compressive strength | - |
Mean compressive strength (minimum) | ≥20 N/mm².Tested to the bed face. Normalized compressive strength: ≥20 N/mm². |
Durability designation | F2 S2. |
Density | - |
Gross dry | 1630 kg/m³. |
Net dry | 1740 kg/m³. |
Tolerance | D1. |
Water absorption | ≤14% m/md.Initial rate of water absorption, to EN 771-1:2011 - 5.3.8:
|
Configuration | Frogged. |
Thermal conductivity | ≤0.60 W/m·K.Lambda 50/50.
|
Water vapour permeability | 5/10 µ. |
Reaction to fire | Class A1 to BS EN 13501-1. |
Jointing | Grey. White. Joint free. Light grey. Dark grey. |
Dangerous substances | NL-BSB. According to Annex ZA 3. |
Unit weight | 2.08 kg. |
Environmental information
Country of material originEurope. | - |
Country of product manufacture | Belgium |
Literature
Vandersanden Coated Bricks Brochure
Vandersanden Coated Bricks Whitepaper
Case studies
Lifelike Visualisation Of Facades Thanks To Vandersanden’s New Texture Generator
Protect the building aesthetic with coated hand-formed bricks
Third party certifications
- CE marked: 0620-CPR-97882
