Cavity System 2 (CS2 External Wall Insulation System) - External Wall Insulation System

Verified by manufacturer 3 months ago

Enviromin mineral finish

SPS Envirowall Ltd Variant:

EuroClass A1 components, mechanically fixed back to the inner sheathing board to create the designed cavity width with the insulation board fitted to a secondary A1 sheathing board and insulation.

Jump to:
0845 1300 983 Website

Application

For the cladding of buildings of all construction types.

Description

Cavity system comprised of EuroClass A1 components, mechanically fixed back to the inner sheathing board to create the designed cavity width with the insulation board fitted to a secondary A1 sheathing board and insulation.


Features and benefits:

  • Kiwa BDA Agrément approved.
  • Accepted by all building warranty providers.
  • Compliant with Approved Document B and Technical Handbook section 2.
  • Minimum EuroClass Reaction to Fire classification of A2–s1, d0.
  • EuroClass A1 support system.
  • Takes cladding out of the critical path by quickly weatherproofing the building.
  • Low-cost cladding solution.
  • Fast application.
  • Tried and tested.
  • Wide range of colours and finishes including brick slips.
  • Easily achieves high levels of thermal performance.
  • Highly durable and weather resistant.

General information

Color

Finish

Textured

Guidance for specification option:

Rendered textured topcoat.

Acrylic

Guidance for specification option:

Acrylic flexible brick slips

Brick

Guidance for specification option:

Acrylic flexible brick slips.

Material

Mineral wool

Guidance for specification option:

A1 rock fibre. Mineral wool external wall insulation board.

Render

Guidance for specification option:

Rendered textured topcoat.

Height

18000 mm

Guidance for specification option:

And above.

Warranty description

12 year

Guidance for specification option:

For system materials.

Uniclass

Ss_25_45_72_28 External wall insulation systemsPrimary

CAWS

M21/210 External wall insulation system

M21/20 External wall insulation system . . . . . .

Specification data - External wall insulation systems

Preparation

-

Manufacturer guidance

Non-SPSenvirowall components:

  • Internal lining/ plasterboard.
  • Vapour control layer (VCL).
  • Lightweight steel studs.
  • Mineral wool insulation between steel studs.
  • Sheathing board suitable of accepting cladding loads.

Support rails and brackets

-

Fixing method

-

Material

CS A1 non-combustible fillets.

Guidance for specification option:

Minimum 15 mm cavity.

Boards

-

Material

CS2 sheathing board (minimum 9 mm).

Insulation

-

Material

Mineral wool insulation mechanically fixed to secondary CS2 sheathing board.

Adhesive

Adhesive mortar.

Fire barriers and stops

-

Material

Intumescent fire break.

Fixings

Fixed to inner sheathing board.

Render carrier or reinforcement

-

Material

High polymer modified basecoat with reinforcing mesh.

Mesh size

Manufacturer's standard.

Fixings

Manufacturer's standard.

Render

-

Application

Finish coat.

Material

Enviromin mineral finish.

Guidance for specification option:

High-performance cement-based and polymer modified through-coloured mineral thin coat render.

Consult manufacturer for full details.

Decorative finish

Textured, standard.

Colour

WH89 White.

SC75 Cream.

SC69 Cream.

BL57 Blue.

CG56 Grey.

LY82 Light Yellow.

GR62 Green.

Bespoke.

Guidance for specification option:

Consult manufacturer for options and insert requirements.

Protective coating

Not required.

NanoSil equalizing finish.

Guidance for specification option:

To Enviromin mineral finish only.

Sustainability data

Material

Mineral wool

Guidance for specification option:

A1 rock fibre. Mineral wool external wall insulation board.

Render

Guidance for specification option:

Rendered textured topcoat.

Recyclability

Mineral wool recycling from site schemes
