Biotex - Polyester Reinforced Membrane
Verified by manufacturer 6 days ago
Recycled and thermo‑bonded polyester, reinforced membrane.
Application
Intended use:
- For internal and external applications, to desolidarize and separate prior to laying of ceramic tile, large formats and natural stone coatings.
- For domestic, commercial, industrial uses.
Suitable substrates:
- Screeds and concrete.
- Existing ceramic tile, marble floor tiles, natural stone, wood, metal , rubber, PVC, linoleum and fibre-glass floorings anchored to the substrate.
- Dry-lay flooring on panels anchored to the substrate.
Description
Recycled and thermo‑bonded polyester, reinforced membrane, specifically designed to absorb shear stresses between substrates and bonded coatings; suitable as reinforcement for the laying of ceramic tiles of all kinds, large formats, porcelain tiles and natural stone.
Biotex increases safety when laying large format tiles with gel adhesives on critical and diverse substrates, increasing the strength of the bonded system and reducing the time required for interventions in renovation work.
Features and benefits:
- Specific for the desolidarizing laying of large formats with H40 gel adhesives.
- Increases shear strength between substrates and coatings.
- Increases safety when laying large formats on critical and old substrates.
- Avoids excessive thicknesses of adhesive in a single coat of laying when levelling any uneven surface.
- High levels of durability over time in basic environments.
- Only 0.65 mm thickness, ideal in renovation work.
General information
Color | Ivory |
Material | Polyester |
Shape | Other Guidance for specification option: Roll. |
Length | 50000 mm |
Width | 1000 mm |
Height | 0.65 mm |
Uniclass | |
CAWS | M40/115 Natural stone covering M40/10 Natural stone covering M41/140 Marble tiling M41/110 Terrazzo tiling M41/110 Terrazzo tiling M40/5 Tiling M40/110 Tiling M40/27 Intermediate substrate M40/470 Intermediate substrate |
Specification data - Plastics sheets
Material | Polyester. |
Purpose | Reinforcement layer. |
Third-party certification | EC 1 plus GEV-Emicode. |
Performance characteristics | |
Tensile strength (minimum) | To ISO 9073-3, 430 N/50 mm. |
Elongation to break | To ISO 9073-3, ≥30%. |
Fire performance | To DIN 4102, B2. |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | Fully recycled. |
Form | Non-woven. |
Physical properties | |
Colour | Ivory. |
Weight (minimum) | 150 g/m². |
Dimensions | |
Thickness (minimum) | 0.65 mm. |
Width (minimum) | 1 m. Manufacturer guidance± 5 mm. |
Roll length (minimum) | 50 m. |
Adhesion | ≥1 N/mm². Manufacturer guidanceShear adhesion after 28 days (ANSI A-118.1). |
Sustainability data
Material | Polyester |
