BioClad® Advanced PVC Hygienic White

Verified by manufacturer 5 months ago

BioClad

High-density polyvinyl chloride (PVC) hygienic cladding system.

Jump to:
+44 (0)330 100 0313 Website

Application

Typical applications:

  • Suitable for walls only.
  • Food manufacturing areas, commercial kitchens, pharmaceutical areas, laboratories, showers, WCs and wet hygienic areas.

Description

Advanced BioClad® PVC Antimicrobial Panel containing Biocote silver ion antimicrobial additive throughout the product thickness with a lifetime guarantee and a single source manufacturer/installer warranty.

Single skin PVC panel with a BioCote® antimicrobial additive to inhibit the growth of bacteria and mould.

High-density, high-quality polyvinyl chloride (PVC) system providing high impact resistance. An alternative solution to tiles, grout-free, easy to clean with a white finish.

Meets all EU regulations making it suitable for food preparation areas and commercial kitchens.


Features and benefits:

  • Resistant to a wide range of chemicals found within the medical, healthcare, and food production industries.
  • PVC panels also don’t flake or corrode.
  • Watertight finish.


Suitable substrates:

  • Good quality fair faced brick or blockwork.
  • Sand and cement rendering 1:3 with a steel trowel finish.
  • 12.5 mm-thick plasterboard.
  • Ceramic tiles which are securely bonded to substrate.
  • 9 mm (minimum) W.P.B resin bonded to substrate.
  • Pink lightweight plasters are generally not suitable.
  • Some surfaces may need PVA sealer subject to site survey.


Components:

Site thermoformed angle sections internal/ external corners, PVC-U cill details, joints and edge trims. As specified B S ‘food safe’ complying with EEC regulations for hygiene in production areas. Directive 64/483 and the requirement as outlined in statutory instruments 454 and 805 (food hygiene).

General information

Color

White

Finish

Satin

Material

Polyvinyl chloride (PVC)

Shape

Rectangle

Length

2440 mm

2800 mm

3050 mm

Width

1220 mm

Height

2.5 mm

Warranty description

20 year

Uniclass

Pr_25_71_14_62 Plastics sheet wall claddingsPrimary

CAWS

K13/145 Proprietary plastics cladding

K13/145 Proprietary plastics cladding

Specification data - Plastics sheet wall claddings

Material

Solid PVC sheet.

Fire performance

To BS 476: Class 1 (Class 0 when bonded to non-combustible substrate).

Thickness

2.5 mm.

Sheet size

1220 x 2440 mm.

1220 x 2800 mm.

1220 x 3050 mm.

Finish

Satin.

Colour

White.

Edges

PVC trimmed.

Adhesive

BioClad trowel applied one-part acrylic adhesive.

BioClad trowel applied two-part polyurethane adhesive.

Joints

Hot welded joint.

Guidance for specification option:

Can be colour matched, consult manufacturer and insert requirement.

Sealant system.

Guidance for specification option:

Can be colour matched, consult manufacturer and insert requirement.

Two part ‘H’ section.

Guidance for specification option:

Standard, colour matched.

Accessories

None.

Edge trim.

Thermo-formed external corner.

Thermo-formed internal corner.

Two-part vinyl floor section.

Fixing

Advanced to part panel adhesive.

Advanced single part 'H' section.

Advanced hot welded joint.

Maximum temperature

60°C.

Volatile organic compounds (VOC) content

0.
