Billi Alpine 120 Instant chilled and ambient filtered water tap system

Billi Alpine 120 Instant chilled and ambient filtered water tap system

Billi UK Third party certifications:
  • QA Certificate

    QA Certificate

    Certificate type

The Billi Alpine utilises Billi’s unique high performance tank, which features superior insulation to keep the water cold, and ensuring less energy is used during the chilling process.

Jump to:
+44 (0) 20 7456 6789 www.billi-uk.com

Application

Can provide 120 cups of chilled water per hour.

Description

Instant filtered drinking water system.

Features and benefits:

  • Provides chilled water.
  • The high performance tank features insulation to keep the water cold, ensuring less energy is used during the chilling process.
  • Designed to maximize available space under the sink.
  • Does not require the use of cupboard ventilation or a cooling fan.
  • The adjustable control knob allows the chilled water temperature to be raised to 15°C or lowered to 6°C for differing refreshment needs. Required temperatures are quickly reached and maintained.
  • The filtration system removes sediment, chemicals, heavy metals, chlorine and pesticides, allows the flow of minerals through and suppresses harmful bacteria in the water.
  • Supplied with a 1 m flex cord and plug.
  • 24-month warranty.

Compliance:

  • WaterMark™ approved.
  • Certified to ATS5200.105 and AS/NZS 4020.

General information

Color

Silver

Black

White

Finish

Brushed Chrome

The standard dispenser and finish is round slimline (R) in chrome (CH) - 932120RCHUK. Consult manufacturer for further details.

Matte

Size

340 x 180 x 460 mm

WarrantyDescription

1 year

24 month parts and labour warranty

Uniclass 2015

Pr_40_70_23_42 Instant boiling and cold water tapsPrimary

CAWS

N11/30 Sinks, taps, traps and wastes

N11/350 Sinks, taps, traps and wastes

N12/380 Sinks, taps, traps and wastes

Specification data - Instant boiling and cold water taps Enhanced data

Duty

-

Electrical connection

-

Power

13 A

Product Reference

Alpine 120 (932120)

Type

Round slimline (R)

Standard

Square slimline (S)

Finish

Brushed Chrome (BR)

Chrome (CH)

Matte Black (MB)

Matte White (MW)

Rose Gold (RG)

Slimline font

Required

Not required

Tubing extension kit (990720)

Required

Not required

Water pressure

2.5–10 bar.

Water supply

A single 15 mm (1/2") stop-tap with a male thread should be installed.

Accessories

Most accessories are available in Chrome (CH), Brushed Chrome (BR), Matte Black (MB), Matte White (MW), Rose Gold (RG). Consult manufacturer for further details.

-

Connection

1 1/2" upstand or appliance spigot on sink waste.

Drainage connection

Digital objects

Platform Compatible Version Certified to
Revit

Revit 2017

2

2.1
IFC
-

2

2.1
Download now from NBS National BIM Library

Third party certifications

  • WaterMark™: Certificate: 21882
