BauderPIR T KL 50 Angle Fillets - Triangular Profiled Insulation Section

Name: BauderPIR T KL 50 Angle Fillets - Triangular Profiled Insulation Section
Brand: Bauder Ltd
SKU: 8fpzG42BvwVFDAmFUPepks

Verified by manufacturer 1 day ago

Product certifications:

BauderPIR angle fillets are a triangular profiled section of BauderPIR insulation.

Jump to:

Application

For use in conjunction with BauderPIR Insulation (specified separately).
Can also be used in cold roof scenarios.
The product is designed to fully support the waterproof membrane at 90° abutments, providing a smooth transition between the horizontal and vertical interface.

BauderPIR angle fillets are a triangular profiled section of BauderPIR insulation.

The product is un-faced and requires priming and gluing prior to application of Bauder underlayers.
Designed to fully support the waterproof membrane at 90° abutments, providing a smooth transition between the horizontal and vertical interface.

Color	Beige
Finish	Unfaced
Material	Polyisocyanurate (PIR)
Shape	Triangle
Length	1000 mm
Width	50 mm Guidance for specification option: Depth (when installed).
Height	50 mm Guidance for specification option: When installed. Manufacturer guidance Thickness.
Warranty description	- Manufacturer guidance A comprehensive range of guarantee options are available. Please contact your local Bauder Area Technical Manager for more information.

Uniclass	Pr_35_90_07_04 Angle filletsPrimary
CAWS	J41/430 Warm deck roof insulation J42/430 Warm deck roof insulation J41/26 Thermal insulation J42/27 Thermal insulation J41/335 Angle fillets J31/26 Thermal insulation

SKU Code	96107050

Classification data
Material	Polyisocyanurate (PIR).
Size (minimum)	50 x 50 mm, triangular in section. Guidance for specification option: Approx. 70 mm across the diagonal. Thickness: 35 mm. Manufacturer guidance Supplied in lengths of 1000 mm as standard.
Surface finish	Top/ bottom: none.
Thermal Conductivity:	To EN 13165 0.026 W/m·K.
Water absorption	To EN 12087, maximum 3 vol%.
Technical characteristics, other	PIR index: >250.
