ASSA ABLOY RR3000 ISO Rigid High Speed Door - Aluminium High-Performance Door

Verified by manufacturer 2 months ago

Assa Abloy Entrance Systems Ltd Product certifications:
  • EPD

    EPD

    Certificate type

A rigid insulated high door speed, opening in vertical direction, for interior and exterior use.

Jump to:
+44 (0)333 006 3443 Website

Application

The perfect solution where vehicle and pedestrian traffic is high in car dealerships, distribution and logistics centres, general manufacturing and much more.

Description

Rigid high speed door, opening in vertical direction, for interior and exterior use.

The ASSA ABLOY RR3000 ISO combines the superior thermal performance of a sectional door with the fast speeds and operational efficiency of a high-performance door. This hybrid solution door opens and closes with maximum speed and minimum energy loss.

Features and benefits:

  • Highly thermally-insulated sandwich lamellas.
  • Sustainable solutions for energy savings.
  • All-weather design for all day operation.
  • Vertical opening.
  • Smart header design.
  • Surface structure increases stiffness and wind load.
  • Light Grid
  • Smart safety system is integrated into the side frames and eliminates contact with objects and people in doorway.
  • Interior and exterior use.
  • Repair kits available for fast and sustainable repairs.
  • Other models in the series: basic, transparent, space-saver and XXL (all specified separately).

General information

Color

Clear

Red

Blue

Orange

Grey

Show more

Finish

Anodized

Galvanized

Powder-coated

Painted

Material

Aluminium

Steel

Shape

Rectangle

Square

Width

Bespoke

Guidance for specification option:

1250–7000 mm.

Height

Bespoke

Guidance for specification option:

2500–6000 mm.

Uniclass

Pr_30_59_24_38 High-speed doorsetsPrimary

CAWS

L20/570 High-speed doors

Specification data - High-speed doorsets

Description

A rigid insulated high door speed, opening in vertical direction, for interior and exterior use.

Manufacturer

ASSA ABLOY Entrance Systems Ltd.

Speed (minimum)

-

Opening

Up to 2.2 m/s.

Closing

Up to 0.7 m/s.

Format

External.
Internal.

Arrangement

Face-fitted across opening.

Curtain material

Thermally-insulated sandwich lamellas.

Guidance for specification option:

Standard.

Aluminium-framed lamellas with polycarbonate windows.

Guidance for specification option:

Double-glazed, framed with anodized aluminium.

Manufacturer guidance

Specify Finish and colour below.

Frame and guides

-

Material

Steel.

Finish and colour

Galvanized.
Powder-coated.

Guidance for specification option:

Insert colour requirements.

Operation

Automatic.

Manufacturer guidance

Manual operation available via crank handle.

Accessories

None.
Electrical safety contact edge.
Door line photocell in side frame (with contact edge).
Curtain monitoring/ crash detector.
LED traffic light.
Traffic light with/ without direction detection.
Flashing alarm light.
Additional opening height.

Guidance for specification option:

Consult manufacturer for details and insert requirements.

Chain drive (space-saving).

Guidance for specification option:

To reduce space for installation on the side.

Crank handle.
Self-testing safety edge and door line photocell.

Guidance for specification option:

Safety feature.

Mechanical locking unit.

Guidance for specification option:

Safety feature.

Standard

To BS EN 13241.

Finish and colour

Colour painted, RAL 9006 White Aluminium.

Guidance for specification option:

Standard.

Colour painted, colour.

Guidance for specification option:

Insert colour requirements.

Cover

Anodized aluminium top roll cover.

Powder-coated top roll cover.

Guidance for specification option:

Insert colour requirements.

Anodized aluminium motor cover.

Powder-coated motor cover.

Guidance for specification option:

Insert colour requirements.

Manufacturer's standard.

Manufacturer guidance

Select multiple options if required.

Control system

Manufacturer's standard (MCC VectorControl™).

With potential-free contacts.

UL-version.

Manufacturer guidance

  • Control voltage: 24 V d.c.
  • Protection: IP 55.
  • Fuse protection by site: 10–16 A (B-characteristics).

Drive unit

Gear motor, 1.1 kW.

Power supply

Guidance for specification option:

Insert requirements.

Supply voltage:

  • 3L/(N)PE 380/ 400/ 415/ 440/ 460/ 480 V; 50/ 60 Hz.
  • With transformer 220/ 230/ 500 V; 50 Hz.
  • UL version: 3L/(N)PE/208/ 220/ 230/ 240/ 460/ 480 V; 60Hz.

Safety

Integrated light grid.
Brake release lever for emergency egress (partial).
Counterbalance (tension spring).

Manufacturer guidance

Standard safety features. See Accessories for further options.

Hardware

Lintel seal.

Operating temperature range

-20°C to +40°C.

Manufacturer guidance

Can be extended on request; consult manufacturer for details.

Resistance to wind load

To BS EN 12424, Class 4.
Class 3 for daylight width >3500 mm.
Class 2 for daylight width >5000 mm.

Acoustic performance

Noise emission to ISO 410-3, 25 dB.

Thermal resistance

K-value according to EN 12428, 1.4 W/m²K (door blade); up to 2.0 W/m²K (complete door).

Guidance for specification option:

Complete door value dependent on door size and specification; consult manufacturer for details.

Sustainability data

Material

Aluminium
Steel

Product certifications

Certified

Product certifications

EPD

EPD

ASSA ABLOY RR3000 ISO rigid high speed door
