Description

Extruded aluminium ogee gutter system.

  • Profile approximates to traditional 'Moulded 46' cast iron gutters.
  • Range of sections suitable for applications including large domestic, commercial and industrial buildings.
  • Gauge: 2 mm (3 mm for largest section).
  • Fix using 25 mm x 12 gauge stainless steel screws.
  • Direct fix to fascia at 600 mm centres, using stainless steel screws. Optional bracket fix.
  • Jointing: Internal joint strap bedded in silicone mastic and secured using stainless steel bolts with coated heads.
  • Powder coated finish with choice of colour. Applied in-house with thirty year guarantee available on application, subject to location.
  • Compatible downpipes listed separately.

General information
Finish

Interpon D, colour ___, gloss level ___

Polyester powder coating.

Syntha Pulvin, colour ___, gloss level ___

Polyester powder coating.

Uniclass 2015
External gravity rainwater drainage systems (Ss_50_30_02_28)Primary
Specification data - External gravity rainwater drainage systems
Product Reference

Arundel Gutter

Layout

As drawing ___

Section (nominal width x depth)

102 x 76 mm

External dimensions 104 x 76 mm.

127 x 102 mm

External dimensions 130 x 100 mm.

152 x 102 mm

External dimensions 155 x 100 mm.

203 x 152 mm

External dimensions 203 x 146 mm.

Outlet

63 mm diameter

Not available on sections 152 x 102 mm or 203 x 152 mm.

76 mm diameter

Not available on sections 152 x 102 mm or 203 x 152 mm.

102 mm diameter

Not available on section 102 x 76 mm.

72 x 72 mm

102 x 76 mm

102 x 102 mm

Not available on section 102 x 76 mm.

Finish

Interpon D, colour ___, gloss level ___

Polyester powder coating.

Syntha Pulvin, colour ___, gloss level ___

Polyester powder coating.

Accessories/ Other requirements

External angle

Internal length: 75 mm each face.

Internal angle

External length: 75 mm each face.

Rafter brackets

Screw to end of rafters when no fascia is used.

Stop end left

Gutter length: 46 mm.

Stop end right

Gutter length: 46 mm.

Standard product features

Plain gutter length:

3 m.

Running outlet length:

250 mm.

Finish:

Consult supplier for colour choice.

– Standard polyester powder coating: Interpon D1036, standard colour range.

  • Electrostatically applied to BS EN 12206 and Qualicoat Class 1 standards.
  • Compliant to ECHA standards which includes Chrome Free solution.
  • Film thickness: 60µ (minimum 50µ).

Product Options

Section:

Indicative flow rates (maximum with central outlet): Roof areas are indicative maxima. Suitable outlet interval varies with local climate and other factors. Consult manufacturer.

– Gutter section 102 x 76 mm. Flow rate: 1.6 L/s.

  • Outlet size 63 mm diameter. Flow rate: 2.4 L/s. Roof area: 115 m².
  • Outlet size 76 mm diameter. Flow rate: 3.3 L/s. Roof area: 158 m².
  • Outlet size 72 x 72 mm. Flow rate: 3.3 L/s. Roof area: 158 m².
  • Outlet size 102 x 76 mm. Flow rate: 3.3 L/s. Roof area: 158 m².

– Gutter section 127 x 102 mm. Flow rate: 3.2 L/s.

  • Outlet size 63 mm diameter. Flow rate: 2.4 L/s. Roof area: 115 m².
  • Outlet size 76 mm diameter. Flow rate: 3.3 L/s. Roof area: 158 m².
  • Outlet size 72 x 72 mm. Flow rate: 3.5 L/s. Roof area: 168 m².
  • Outlet size 102 mm diameter. Flow rate: 5.3 L/s. Roof area: 254 m².
  • Outlet size 102 x 76 mm. Flow rate: 5 L/s. Roof area: 240 m².
  • Outlet size 102 x 102 mm. Flow rate: 5.7 L/s. Roof area: 274 m².

– Gutter section 152 x 102 mm. Flow rate: 3.7 L/s.

  • Outlet size 76 mm diameter. Flow rate: 3.3 L/s. Roof area: 158 m².
  • Outlet size 102 mm diameter. Flow rate: 5.8 L/s. Roof area: 279 m².
  • Outlet size 72 x 72 mm. Flow rate: 3.6 L/s. Roof area: 173 m².
  • Outlet size 102 x 76 mm. Flow rate: 5.4 L/s. Roof area: 260 m².
  • Outlet size 102 x 102 mm. Flow rate: 6.8 L/s. Roof area: 327 m².

– Gutter section 203 x 152 mm. Flow rate: 7.5 L/s.

  • Outlet size 76 mm diameter. Flow rate: 4.2 L/s. Roof area: 200 m².
  • Outlet size 102 mm diameter. Flow rate: 7.5 L/s. Roof area: 360 m².
  • Outlet size 152 mm diameter. Flow rate: 15 L/s. Roof area: 720 m².
  • Outlet size 72 x 72 mm. Flow rate: 4.5 L/s. Roof area: 215 m².
  • Outlet size 102 x 76 mm. Flow rate: 6.7 L/s. Roof area: 320 m².
  • Outlet size 102 x 102 mm. Flow rate: 9 L/s. Roof area: 430 m².
